| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 14X-54-72151 | Bracket | 90023- | |
| 2 | 14X-54-72141 | Bracket | 90023- | |
| 3 | 14X-54-72391 | Bracket | 90023- | |
| 4 | 01010-81235 | Bolt | 90023- | |
| 5 | 01643-31232 | Washer | 90023- | |
| 6 | 01643-31232 | Washer | 90023- | |
| 7 | 04050-14025 | Pin, Cotter | 90023- |
- Главная
- Каталог запчастей
- Бульдозеры
- D65exi 18 s/n 90023 up
- Guards and covers
- Front guard, bracket (#90023 )
Поиск по каталогу
Front Guard, Bracket (#90023-)
