| Item | Part No. | Part Name | Qty | Serial No. |
| 131-30-00273 | IDLER ASS'Y,L.H. | .- | ||
| 131-30-00283 | IDLER ASS'Y,R.H. | .- | ||
| 131-30-00272 | IDLER ASS'Y | 3221-. | ||
| 131-30-00271 | IDLER ASS'Y | 1007-3220 | ||
| 130-30-00086 | IDLER ASS'Y | 3221- | ||
| 130-30-00085 | IDLER ASS'Y | 1007-3220 | ||
| 1 | 130-30-13115 | IDLER | 1007- | |
| 131-30-00110 | BUSHING ASS'Y | .- | ||
| 140-30-00032 | BUSHING ASS'Y | 1007-. | ||
| 2 | 131-30-46120 | BUSHING | .- | |
| 140-30-16181 | BUSHING | 1007-. | ||
| 3 | 131-30-46130 | BUSHING | 4004- | |
| 140-30-16290 | BUSHING | 3991-4003 | ||
| 131-30-46130 | BUSHING | 3983-3990 | ||
| 140-30-16290 | BUSHING | 2002-3982 | ||
| \0\140-30-16191 | BUSHING | 1007-1999 | ||
| 4 | 141-30-36310 | PIN | 4004- | |
| 04025-00512 | PIN | 3991-4003 | ||
| 141-30-36310 | PIN | 3983-3990 | ||
| 04025-00512 | PIN | 1007-3982 | ||
| 5 | 07000-03092 | O-RING | 1007- | |
| 6 | 130-30-13129 | SHAFT | 1007- | |
| 7 | 07052-11624 | PLUG | 3221- | |
| 07052-01624 | PLUG | 1007-3220 | ||
| 8 | 01010-31025 | BOLT | 1007- | |
| 9 | 01602-01030 | WASHER | 1007- | |
| 10 | 07000-03048 | O-RING | 1007- | |
| 140-30-00040 | FLOATING SEAL ASS'Y | 1007- | ||
| 11 | \6\ | RING,SEAL | 1007- | |
| 12 | 140-30-16220 | O-RING | 1007- | |
| 13 | 141-30-13291 | BRACKET,R.H. | 1007- | |
| 13 | 141-30-13132 | BRACKET | 1007- | |
| 14 | 141-30-13141 | PLATE | 1007- | |
| 141-30-13281 | BRACKET,L.H. | 1007- | ||
| 15 | 141-30-13122 | BRACKET | 1007- | |
| 16 | 141-30-13141 | PLATE | 1007- | |
| 17 | 141-30-13410 | GUIDE | 3221- | |
| 141-30-13310 | GUIDE | 1007-3220 | ||
| 18 | 141-30-13420 | GUIDE | 3221- | |
| 141-30-13320 | GUIDE | 1007-3220 | ||
| 19 | 01010-31640 | BOLT | 3221- | |
| 01040-31640 | BOLT | 1007-3220 | ||
| 20 | 01010-31660 | BOLT | 3221- | |
| 01040-31660 | BOLT | 1007-3220 | ||
| 21 | 01602-01648 | WASHER | 1007- | |
| 141-30-05021 | SHIM ASS'Y | 1007- | ||
| 22 | 141-30-13251 | SHIM¤ 1.0MM | 1007- | |
| 23 | 130-30-13170 | BOLT | 1007- | |
| 24 | 01582-01613 | NUT | 3221- | |
| 01500-31613 | NUT | 1007-3220 | ||
| 25 | 01640-01629 | WASHER | 1007- | |
| 26 | 01602-01648 | WASHER | 1007- |
