| Item | Part No. | Part Name | Qty | Serial No. |
| 175-30-00575 | FRONT IDLER ASS'Y | 23458- | ||
| \0\175-30-00574 | FRONT IDLER ASS'Y | 19661-23457 | ||
| \0\175-30-00573 | FRONT IDLER ASS'Y | 19001-19660 | ||
| \0\175-30-00572 | FRONT IDLER ASS'Y | 17001-19000 | ||
| 175-30-00571 | FRONT IDLER ASS'Y | 12419-17000 | ||
| \0\175-30-00570 | FRONT IDLER ASS'Y | 10263-12418 | ||
| 1 | 175-30-23114 | IDLER | 5508- | |
| 2 | 175-30-23121 | SHAFT | 5508- | |
| 3 | 07052-21624 | PLUG | 6091- | |
| 175-30-36108 | BUSHING ASS'Y | 5957- | ||
| 4 | \6\ | BUSHING | 8651- | |
| 5 | \6\ | BUSHING | 6843- | |
| 6 | 170-30-91130 | PIN | 5508- | |
| 7 | 07000-02130 | O-RING | 5508- | |
| 175-30-00702 | FLOATING SEAL ASS'Y | 23458- | ||
| \0\175-30-00701 | FLOATING SEAL ASS'Y | 19661-23457 | ||
| \0\175-30-00700 | FLOATING SEAL ASS'Y | 12419-19660 | ||
| \0\170-30-00111 | FLOATING SEAL ASS'Y | 5508-12418 | ||
| 8 | 175-30-00691 | SEAL RING ASS'Y | 19661- | |
| \0\175-30-00690 | SEAL RING ASS'Y | 12419-19660 | ||
| \0\170-30-00180 | SEAL RING ASS'Y | 5508-12418 | ||
| \6\ | RING,SEAL | 19661- | ||
| \6\ | RING,SEAL | 12419-19660 | ||
| \6\ | RING,SEAL | 5508-12418 | ||
| 9 | 175-30-00581 | O-RING ASS'Y | 23458- | |
| \0\175-30-00580 | O-RING ASS'Y | 5508-23457 | ||
| \6\ | O-RING | 23458- | ||
| \6\ | O-RING | 5508-23457 | ||
| 10 | 07000-03068 | O-RING | 5508- | |
| 11 | 01010-31235 | BOLT | 5508- | |
| 12 | 01602-01236 | WASHER,SPRING | 5508- | |
| 175-30-33273 | GUIDE ASS'Y | 23458- | ||
| \0\175-30-33272 | GUIDE ASS'Y | 19001-23457 | ||
| 175-30-33271 | GUIDE ASS'Y | 10263-19000 | ||
| 13 | \6\ | GUIDE | 23458- | |
| \6\ | GUIDE | 19001-23457 | ||
| \6\ | GUIDE | 10263-19000 | ||
| 14 | 170-30-13343 | PLATE | 19001- | |
| \0\175-30-33290 | PLATE | 8651-19000 | ||
| 15 | 04022-12025 | PIN | 23458- | |
| 04020-01228 | PIN,DOWEL | 8651-23457 | ||
| 16 | 176-30-43111 | SUPPORT | 17001- | |
| 175-30-33251 | SUPPORT | 10263-17000 | ||
| 17 | 176-30-43121 | SUPPORT | 17001- | |
| 175-30-33261 | SUPPORT | 10263-17000 | ||
| 18 | 175-30-23172 | BOLT | 10263- | |
| 19 | 175-30-23180 | NUT | 8651- | |
| 20 | 01602-01648 | WASHER,SPRING | 5508-25000 | |
| 21 | 01643-31645 | WASHER | 5508- | |
| 22 | 175-30-05050 | SHIM KIT | 10263- | |
| \6\ | SHIM¤ 1.0MM | 10263- | ||
| 23 | \6\ | SHIM¤ 2.0MM | 10263- | |
| 24 | 175-30-05060 | SHIM KIT | 10263- | |
| \6\ | SHIM¤ 1.0MM | 10263- | ||
| 25 | \6\ | SHIM¤ 2.0MM | 10263- | |
| 26 | 175-30-33460 | PLATE | 10263- | |
| 27 | 175-30-33492 | BOLT | 17001- | |
| 175-30-33491 | BOLT | 10263-17000 | ||
| 28 | 01602-02060 | WASHER | 10263- | |
| 29 | 175-30-33471 | COVER | 10263-19000 | |
| 30 | 175-30-33481 | COVER | 10263-19000 | |
| 31 | 01010-31635 | BOLT | 10263-19000 | |
| 32 | 01602-01648 | WASHER,SPRING | 10263-19000 | |
| 33 | 175-30-33215 | PLATE | 23571- | |
| \0\175-33-33214 | PLATE | 10263-23570 | ||
| 34 | 175-30-05070 | SHIM KIT | 10263- | |
| \6\ | SHIM¤ 1.0MM | 10263- | ||
| \6\ | SHIM¤ 0.5MM | 10263- | ||
| 35 | 01011-32260 | BOLT | 10263- | |
| 36 | 01602-02268 | WASHER,SPRING | 10263- | |
| 37 | 175-30-33430 | SEAT | 10263- | |
| 38 | 195-30-17960 | SEAT | 8651- | |
| 39 | 155-30-13230 | SPRING | 8651- | |
| 40 | 175-30-24131 | SEAT | 8651- |
