| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 566-54-8A343 | COVER | 7001- | |
| 2 | 01010-81020 | BOLT | 7001- | |
| 3 | 01643-31032 | WASHER | 7001- | |
| 4 | 566-54-8A421 | PLATE | 7001- | |
| 5 | 01010-81016 | BOLT | 7001- | |
| 6 | 01643-31032 | WASHER | 7001- | |
| 7 | 566-54-8A430 | PLATE | 7001- | |
| 8 | 01010-80812 | BOLT | 7001- | |
| 9 | 01643-30823 | WASHER | 7001- | |
| 10 | 566-54-8A440 | PLATE | 7001- | |
| 11 | 01010-81016 | BOLT | 7001- | |
| 12 | 01643-31032 | WASHER | 7001- | |
| 13 | 09415-05016 | CAP | 7001- | |
| 14 | 09415-02512 | CAP | 7001- | |
| 15 | 566-06-6A310 | LAMP ASS'Y | 7001- | |
| 15 | 23S-06-54121 | LENS ASS'Y | 7001- | |
| 15 | 421-06-23330 | BULB, 70W | 7001- | |
| 16 | 23B-06-42460 | LAMP ASS'Y | 7001- | |
| 16 | 41G-06-13210 | LENS | 7001- | |
| 16 | 41G-06-13220 | LENS | 7001- | |
| 16 | 41G-06-13230 | BULB, 5W | 7001- | |
| 16 | 08105-12420 | BULB, 25W | 7001- | |
| 17 | 566-06-84351 | BRACKET,L.H. | 7001- | |
| 18 | 01010-81245 | BOLT | 7001- | |
| 19 | 01643-31232 | WASHER | 7001- | |
| 20 | 419-43-17920 | WASHER | 7001- | |
| 21 | 419-43-17930 | CUSHION | 7001- | |
| 22 | 415-64-13130 | CUSHION | 7001- | |
| 23 | 417-54-13470 | SPACER | 7001- | |
| 24 | 566-06-84162 | WIRING HARNESS | 7009- | |
| 24 | 566-06-84161 | WIRING HARNESS | 7001-7008 | |
| 25 | 08053-01510 | CLIP | 7001- | |
| 26 | 01010-81016 | BOLT | 7001- | |
| 27 | 01643-31032 | WASHER | 7001- | |
| 28 | 04434-51010 | CLIP | 7001- | |
| 29 | 01010-81016 | BOLT | 7001- | |
| 30 | 01643-31032 | WASHER | 7001- | |
| 31 | 04434-51012 | CLIP | 7009- |
