| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 56B-61-3A431 | Cover | 5129- | |
| 2 | 01010-81020 | Bolt | 5129- | |
| 3 | 01643-31032 | Washer | 5129- | |
| 4 | 56B-03-31580 | Cover | 5129- | |
| 5 | 01010-81020 | Bolt | 5129- | |
| 6 | 01643-31032 | Washer | 5129- |
- Главная
- Каталог запчастей
- Самосвалы
- Hm400 3m0 s/n 5129 up ( 40°c spec.)
- Hydraulic system
- Front steering and hoist hydraulic piping, cover (#5129 )
Поиск по каталогу
Front Steering and Hoist Hydraulic Piping, Cover (#5129-)
