| Item | Part No. | Part Name | Qty | Serial No. |
| 267-80-11629 | TUBE | 1047-1066 | ||
| 267-80-11620 | TUBE | 1067-1096 | ||
| 1 | 267-80-11621 | TUBE | 1097-1206 | |
| 2 | 267-80-11640 | BRACKET | 1047-@ | |
| 3 | 01000-30816 | BOLT | 1047-@ | |
| 4 | 01602-00825 | WASHER | 1047-@ | |
| 5 | 01000-30820 | BOLT | 1047-@ | |
| 6 | 01500-30807 | NUT | 1047-@ | |
| 7 | 01602-00825 | WASHER | 1047-@ | |
| 8 | 267-80-11630 | BRACKET | 1047-1206 | |
| 9 | 01000-30816 | BOLT | 1047-1206 | |
| 10 | 01602-00825 | WASHER | 1047-1206 | |
| 11 | 01000-30820 | BOLT | 1047-1206 | |
| 12 | 01500-30807 | NUT | 1047-1206 | |
| 13 | 01602-00825 | WASHER | 1047-1206 | |
| 14 | 266-13-08000 | ELBOW | 1047-1206 | |
| 15 | 266-80-12210 | NIPPLE | 1047-1206 | |
| 16 | 267-80-11690 | HOSE | 1047-1206 | |
| 17 | 266-92-10026 | CLAMP | 1147-1206 | |
| \0\267-92-30027 | CLAMP | 1047-1146 | ||
| 18 | 266-13-08000 | ELBOW | 1047-1206 | |
| 19 | 266-80-12210 | NIPPLE | 1047-1206 | |
| 20 | 267-92-10026 | CLAMP | 1147-1206 | |
| 267-92-30027 | CLAMP | 1047-1146 | ||
| 21 | 267-80-11660 | TUBE | 1047-1206 | |
| 22 | 267-80-11800 | BRACKET | 1047-1206 | |
| 23 | 01000-30816 | BOLT | 1047-1206 | |
| 24 | 01602-00825 | WASHER | 1047-1206 | |
| 25 | 01000-30820 | BOLT | 1047-1206 | |
| 26 | 01500-30807 | NUT | 1047-1206 | |
| 27 | 01602-00825 | WASHER | 1047-1206 | |
| 28 | 267-80-11800 | BRACKET | 1047-1206 | |
| 29 | 01000-30816 | BOLT | 1047-1206 | |
| 30 | 01602-00825 | WASHER | 1047-1206 | |
| 31 | 01000-30820 | BOLT | 1047-1206 | |
| 32 | 01500-30807 | NUT | 1047-1206 | |
| 33 | 01702-00825 | WASHER | 1047-1206 | |
| 34 | 266-13-08000 | ELBOW | 1047-1206 | |
| 35 | 267-80-11670 | TUBE | 1047-1206 | |
| 36 | 267-80-11900 | BRACKET | 1047-1206 | |
| 37 | 01000-30816 | BOLT | 1047-1206 | |
| 38 | 01500-30807 | NUT | 1047-1206 | |
| 39 | 01602-00825 | WASHER | 1047-1206 | |
| 40 | 01000-30820 | BOLT | 1047-1206 | |
| 41 | 01500-30807 | NUT | 1047-1206 | |
| 42 | 01602-00825 | WASHER | 1047-1206 | |
| 43 | 265-98-08000 | ELBOW | 1047-1096 | |
| 43 | 266-13-08000 | ELBOW | 1097-1206 | |
| 44 | 266-80-12250 | VALVE | 1047-1097 | |
| 45 | 266-80-12210 | NIPPLE | 1047-1206 | |
| 46 | 267-80-11710 | HOSE | 1047-1206 | |
| 47 | 266-92-10026 | CLAMP | 1047-1206 | |
| 48 | 267-80-12100 | TUBE | 1047-1206 | |
| 49 | 266-92-10026 | CLAMP | 1047-1206 | |
| 50 | 01040-31025 | BOLT | 1047-1206 | |
| 51 | 01602-01030 | WASHER | 1047-1206 | |
| 52 | 267-80-11740 | PLUG | 1047-1206 |
