| Item | Part No. | Part Name | Qty | Serial No. |
| 416-22-10010 | AXLE ASS'Y,FRONT | 20001- | ||
| \0\417-22-10001 | AXLE ASS'Y,FRONT | 10001-19999 | ||
| 1 | 417-22-12411 | SHAFT | 10001- | |
| 2 | 417-22-12850 | BEARING | 10001- | |
| 3 | 417-22-12460 | SEAL | 10001- | |
| 4 | 417-22-12840 | BEARING | 10001- | |
| 5 | 417-22-12612 | CARRIER | 20001- | |
| 5 | \0\417-22-12611 | CARRIER | 10001-19999 | |
| 6 | 417-22-12350 | SPACER | 10001- | |
| 7 | 417-22-12360 | SHIM, 0.05MM | 10001- | |
| 7 | 417-22-12370 | SHIM, 0.2MM | 10001- | |
| 7 | 417-22-12380 | SHIM, 0.3MM | 10001- | |
| 7 | 417-22-12390 | SHIM, 0.8MM | 10001- | |
| 8 | 01010-61685 | BOLT | 10001- | |
| 9 | 417-22-12530 | GEAR | 10001- | |
| 10 | 417-22-12810 | BEARING,CONE | 10001- | |
| 11 | 419-22-12260 | SHIM, 1.0MM | 10001- | |
| 11 | 419-22-12270 | SHIM, 1.2MM | 10001- | |
| 11 | 419-22-12280 | SHIM, 1.4MM | 10001- | |
| 12 | 417-22-12510 | SHAFT | 10001- | |
| 13 | 419-22-12570 | PIN | 10001- | |
| 14 | 417-22-12540 | GEAR | 10001- | |
| 15 | 417-22-12580 | PIN | 10001- | |
| 16 | 417-33-11262 | PLATE | 10001- | |
| 17 | 417-22-12421 | SHAFT | 10001- | |
| 18 | 417-33-11420 | O-RING | 10001- | |
| 19 | 417-33-11122 | PISTON | 10001- | |
| 20 | 417-33-11410 | O-RING | 10001- | |
| 21 | 417-33-11252 | PLATE | 10001- | |
| 22 | 417-33-11243 | DISC | 10001- | |
| 23 | 417-22-12910 | BOLT | 10001- | |
| 24 | 01643-32460 | WASHER | 10001- |
