Item | Part No. | Part Name | Qty | Serial No. |
1 | 104-43-41250 | LEVER ASS'Y | 78604- | |
1 | 114-43-48220 | LEVER ASS'Y | 75001-78603 | |
2 | 203-43-44360 | KNOB | 75001- | |
3 | 07372-21030 | BOLT | 75001- | |
4 | 01602-21030 | WASHER,SPRING | 75001- | |
5 | 101-43-58111 | BRACKET | 75001- | |
6 | 14Y-43-11121 | YOKE | 75001- | |
7 | 363-43-27260 | BEARING | 75001- | |
8 | 114-43-48770 | BRACKET | 75001- | |
9 | 01010-51025 | BOLT | 75001- | |
10 | 01010-51020 | BOLT | 75001- | |
11 | 01643-31032 | WASHER | 75001- | |
12 | 101-43-58122 | COVER | 76441- | |
12 | 101-43-58121 | COVER | 75001-76440 | |
13 | 114-43-48241 | GROMMET | 75001- | |
14 | 01252-30825 | BOLT | 75001- | |
15 | 01643-30823 | WASHER | 75001- | |
16 | 114-54-43260 | PLUG | 75001- | |
17 | 21X-43-12121 | CABLE | 78604- | |
17 | 103-43-35270 | CABLE | 75001-78603 | |
18 | 103-43-25160 | END,ROD | 75001- | |
19 | 01580-10504 | NUT | 75001- | |
20 | 01601-20513 | WASHER,SPRING | 75001- | |
21 | 04211-20500 | YOKE | 75001- | |
22 | 04205-10516 | PIN | 75001- | |
23 | 01641-20508 | WASHER | 75001- | |
24 | 04050-11208 | PIN,COTTER | 75001- | |
25 | 104-43-41161 | BRACKET | 78604- | |
25 | 103-43-35180 | BRACKET | 75001-78603 | |
26 | 01010-51020 | BOLT | 75001- | |
27 | 01602-21030 | WASHER,SPRING | 75001- | |
28 | 104-43-38510 | EXTENSION,(WITH CAB) | 76734- | |
29 | 104-43-38520 | NUT,(WITH CAB) | 76734- | |
30 | 114-X11-2590 | SEAL,(WITH CAB) | 76734- |
