| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 566-84-81130 | HOSE | 4001-@ | |
| 2 | 07206-31014 | BOLT | 4001-@ | |
| 3 | 07005-01412 | GASKET | 4001-@ | |
| 4 | 07102-20516 | HOSE | 4001-@ | |
| 5 | 07102-20516 | HOSE | 4001-@ | |
| 6 | 561-04-61391 | BRACKET | 4001-@ | |
| 7 | 512-16-11450 | PLATE | 4001-@ | |
| 8 | 01010-81030 | BOLT | 4001-@ | |
| 9 | 01643-31032 | WASHER | 4001-@ | |
| 10 | 01010-81035 | BOLT | 4001-@ | |
| 11 | 561-88-66440 | BRACKET | 4001-@ | |
| 12 | 01010-82040 | BOLT | 4001-@ | |
| 13 | 01643-32060 | WASHER | 4001-@ | |
| 14 | 07005-01412 | GASKET | 4001-@ | |
| 15 | 07206-31014 | BOLT | 4001-@ | |
| 16 | 07102-20434 | HOSE | 4001-@ | |
| 17 | 07102-20433 | HOSE | 4001-@ | |
| 18 | 6128-71-1932 | JOINT | 4001-@ | |
| 19 | 424-09-12570 | CLIP | 4001-@ | |
| 20 | 581-35-23540 | INSULATOR | 4001-@ | |
| 21 | 569-04-61330 | CLIP | 4001-@ | |
| 22 | 566-61-49810 | INSULATOR | 4001-@ | |
| 23 | 424-09-12570 | CLIP | 4001-@ | |
| 24 | 561-43-41620 | INSULATOR | 4001-@ | |
| 25 | 01010-81220 | BOLT | 4001-@ | |
| 26 | 01643-31232 | WASHER | 4001-@ | |
| 27 | 07102-20355 | HOSE | 4001-4098 | |
| 28 | 07102-20349 | HOSE | 4001-4098 | |
| 29 | 07238-00315 | CONNECTOR | 4001-@ | |
| 30 | 561-04-61290 | PLATE | 4001-@ | |
| 31 | 561-04-6A290 | PLATE | 4001-@ | |
| 32 | 561-04-61280 | BRACKET | 4001-@ | |
| 33 | 07043-70211 | PLUG | 4001-@ | |
| 34 | 07283-27671 | CLIP | 4001-@ | |
| 35 | 01643-31032 | WASHER | 4001-@ | |
| 36 | 01599-01011 | NUT | 4001-@ | |
| 37 | 569-04-61330 | CLIP | 4001-@ | |
| 38 | 566-61-49810 | INSULATOR | 4001-@ | |
| 39 | 01010-81030 | BOLT | 4001-@ | |
| 40 | 01580-11008 | NUT | 4001-@ | |
| 41 | 01643-31032 | WASHER | 4001-@ |
