| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 582-35-11170 | CLIP | 11001- | |
| 2 | 07095-20523 | CUSHION | 11001- | |
| 3 | 22M-62-22370 | CUSHION | 11001- | |
| 4 | 04434-52112 | CLIP | 11001- | |
| 5 | 07095-20314 | CUSHION | 11001- | |
| 6 | 421-03-11530 | SPACER | 11001- | |
| 7 | 01010-81035 | BOLT | 11001- | |
| 8 | 01643-31032 | WASHER | 11001- | |
| 9 | 582-35-11170 | CLIP | 11001- | |
| 10 | 07095-20523 | CUSHION | 11001- | |
| 11 | 22M-62-22370 | CUSHION | 11001- | |
| 12 | 04434-52112 | CLIP | 11001- | |
| 13 | 07095-20314 | CUSHION | 11001- | |
| 14 | 01010-81016 | BOLT | 11001- | |
| 15 | 01643-31032 | WASHER | 11001- | |
| 16 | 04434-53212 | CLIP | 11001- | |
| 17 | 07095-20523 | CUSHION | 11001- | |
| 18 | 01010-81020 | BOLT | 11001- | |
| 19 | 01643-31032 | WASHER | 11001- | |
| 20 | 04434-52112 | CLIP | 11001- | |
| 21 | 07095-20314 | CUSHION | 11001- | |
| 22 | 01010-81020 | BOLT | 11001- | |
| 23 | 01643-31032 | WASHER | 11001- | |
| 24 | 566-04-81130 | PLATE | 11001- | |
| 25 | 01010-81020 | BOLT | 11001- | |
| 26 | 01643-31032 | WASHER | 11001- | |
| 27 | 582-35-11170 | CLIP | 11001- | |
| 28 | 07095-20523 | CUSHION | 11001- | |
| 29 | 22M-62-22370 | CUSHION | 11001- | |
| 30 | 04434-52112 | CLIP | 11001- | |
| 31 | 07095-20314 | CUSHION | 11001- | |
| 32 | 01010-81025 | BOLT | 11001- | |
| 33 | 01643-31032 | WASHER | 11001- |
