| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 582-35-11170 | CLIP | 7001- | |
| 2 | 07095-20523 | CUSHION | 7001- | |
| 3 | 22M-62-22370 | CUSHION | 7001- | |
| 4 | 421-62-11940 | PLATE | 7001- | |
| 5 | 04434-53212 | CLIP | 7001- | |
| 6 | 07095-20523 | CUSHION | 7001- | |
| 7 | 04434-52112 | CLIP | 7001- | |
| 8 | 07095-20314 | CUSHION | 7001- | |
| 9 | 01010-81025 | BOLT | 7001- | |
| 10 | 01643-31032 | WASHER | 7001- | |
| 11 | 417-54-15541 | SPACER | 7001- | |
| 12 | 01010-81060 | BOLT | 7001- | |
| 13 | 01643-31032 | WASHER | 7001- | |
| 14 | 04434-53212 | CLIP | 7001- | |
| 15 | 07095-20523 | CUSHION | 7001- | |
| 16 | 04434-52112 | CLIP | 7001- | |
| 17 | 07095-20314 | CUSHION | 7001- | |
| 18 | 416-881-1140 | PLATE | 7001- | |
| 19 | 07283-32244 | CLIP | 7001- | |
| 20 | 01597-01009 | NUT | 7001- | |
| 21 | 01643-31032 | WASHER | 7001- | |
| 22 | 04434-52112 | CLIP | 7001- | |
| 23 | 07095-20314 | CUSHION | 7001- | |
| 24 | 07095-20314 | CUSHION | 7001- | |
| 25 | 04434-52112 | CLIP | 7001- | |
| 26 | 01010-81016 | BOLT | 7001- | |
| 27 | 01643-31032 | WASHER | 7001- | |
| 28 | 07095-20314 | CUSHION | 7001- | |
| 29 | 04434-52112 | CLIP | 7001- | |
| 30 | 07095-20314 | CUSHION | 7001- | |
| 31 | 04434-52112 | CLIP | 7001- | |
| 32 | 01010-81016 | BOLT | 7001- | |
| 33 | 01643-31032 | WASHER | 7001- | |
| 34 | 566-04-81140 | PLATE | 7001- | |
| 35 | 01010-81020 | BOLT | 7001- | |
| 36 | 01643-31032 | WASHER | 7001- | |
| 37 | 04434-53212 | CLIP | 7001- | |
| 38 | 07095-20523 | CUSHION | 7001- | |
| 39 | 01010-81020 | BOLT | 7001- | |
| 40 | 01643-31032 | WASHER | 7001- |
