| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 312607752 | PIPE | 150EF80001- | |
| 2 | 885220017 | PROTECTION L=2500 | 150EF80001- | |
| 3 | 802660002 | CLAMP | 150EF80001- | |
| 4 | 312607751 | HOSE | 150EF80001- | |
| 5 | 885220017 | PROTECTION L=1000 | 150EF80001- | |
| 6 | 306404639 | HOSE | 150EF80001- | |
| 7 | 885220017 | PROTECTION L=1300 | 150EF80001- | |
| 8 | 500358755 | UNION | 150EF80001- | |
| 9 | 855150034 | GASKET | 150EF80001- | |
| 10 | 802660028 | COLLAR | 150EF80001- | |
| 11 | 801015108 | BOLT | 150EF80001- | |
| 12 | 802170002 | WASHER | 150EF80001- | |
| 13 | 801015109 | BOLT | 150EF80001- | |
| 14 | 801015088 | BOLT | 150EF80001- | |
| 15 | 802170001 | WASHER | 150EF80001- | |
| 16 | 802660505 | COLLAR | 150EF80001- | |
| 17 | 801015086 | BOLT | 150EF80001- | |
| 18 | 802170001 | WASHER | 150EF80001- | |
| 19 | 802660507 | COLLAR | 150EF80001- | |
| SEE FIG. 0411 | ||||
| SEE FIG. 1300 |
