| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 600-311-9800 | WATER SEPARATOR A. | 1001- | |
| 2 | 01010-50825 | BOLT | 1001- | |
| 3 | 01643-30823 | WASHER | 1001- | |
| 4 | 600-311-9500 | FILTER ASS'Y,FUEL | 1001- | |
| 5 | 01010-50830 | BOLT | 1001- | |
| 6 | 01643-30823 | WASHER | 1001- | |
| 7 | 201-04-61110 | BRACKET | 1001- | |
| 8 | 01010-51020 | BOLT | 1001- | |
| 9 | 01643-31032 | WASHER | 1001- | |
| 10 | 205-06-62150 | JOINT | 1001- | |
| 11 | 07206-31014 | BOLT,JOINT | 1001- | |
| 12 | 07005-01412 | GASKET | 1001- | |
| 13 | 07288-01001 | HOSE | 1001- | |
| 14 | 07281-00197 | CLAMP | 1001- | |
| 15 | 6144-71-5760 | JOINT | 1001- | |
| 16 | 205-04-62140 | JOINT | 1001- | |
| 17 | 07206-31014 | BOLT,JOINT | 1001- | |
| 18 | 07005-01412 | GASKET | 1001- | |
| 19 | 07700-40240 | VALVE | 1001- | |
| 20 | 203-04-31130 | NIPPLE | 1001- | |
| 21 | 07288-01034 | HOSE | 1001- | |
| 22 | 07288-01025 | HOSE | 1001- | |
| 23 | 07281-00197 | CLAMP | 1001- | |
| 24 | 08036-01814 | CLIP | 1001- | |
| 25 | 01010-51016 | BOLT | 1001- | |
| 26 | 01643-31032 | WASHER | 1001- | |
| 27 | 208-06-12110 | CLIP | 1001- | |
| 28 | 01010-51016 | BOLT | 1001- | |
| 29 | 01010-31032 | BOLT | 1001- | |
| 30 | 08036-02514 | CLIP | 1001- | |
| 31 | 01010-51016 | BOLT | 1001- | |
| 32 | 01643-31032 | WASHER | 1001- | |
| 33 | 08036-02514 | CLIP | 1001- | |
| 34 | 103-21-21260 | BOSS | 1001- | |
| 35 | 01010-51025 | BOLT | 1001- | |
| 36 | 01643-31032 | WASHER | 1001- | |
| 37 | 08034-00519 | BAND | 1001- | |
| 38 | 201-46-38220 | GROMMET | 1001- | |
| 39 | 20X-06-31130 | GROMMET | 1001- |
