| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 131-04-43130 | STRAINER | 1002-@ | |
| 2 | 01010-50812 | BOLT | 1002-@ | |
| 3 | 01602-20825 | WASHER | 1002-@ | |
| 4 | 125-04-13110 | FLANGE | 1002-@ | |
| 5 | 07000-02135 | O-RING | 1002-@ | |
| 6 | 01010-51020 | BOLT | 1002-@ | |
| 7 | 01602-21030 | WASHER | 1002-@ | |
| 8 | 566-04-13380 | NIPPLE | 1002-1012 | |
| 9 | 568-04-12100 | HOSE ASS'Y | 1002-1012 | |
| 10 | 566-04-13430 | SOCKET | 1002-1012 | |
| 11 | 566-04-13320 | NIPPLE | 1002-1012 | |
| 12 | 01582-12419 | NUT | 1002-1012 | |
| 13 | 01602-22472 | WASHER | 1002-1012 | |
| 14 | 07700-20504 | VALVE | 1002-@ | |
| 15 | 145-04-14110 | NIPPLE | 1013-@ | |
| 15 | 145-04-14110 | NIPPLE | 1002-1012 | |
| 16 | 131-04-54130 | ELBOW | 1002-@ | |
| 17 | 566-04-11280 | NIPPLE | 1002-@ | |
| 18 | 02750-03380 | HOSE | 1002-@ | |
| 19 | 07102-20545 | HOSE | 1013-@ | |
| 19 | 02750-04360 | HOSE | 1002-1012 | |
| 20 | 566-04-12260 | NIPPLE | 1002-1012 | |
| 21 | 08036-10814 | CLIP | 1002-1034 | |
| 22 | 08036-01814 | CLIP | 1002-1034 | |
| 23 | 01010-51016 | BOLT | 1002-@ | |
| 24 | 01602-21030 | WASHER | 1002-@ | |
| 25 | 566-07-11780 | CLIP | 1002-@ | |
| 26 | 07822-00470 | TUBE | 1002-1034 | |
| 27 | 565-44-15331 | JOINT | 1002-1034 | |
| 28 | 281-35-19360 | CONNECTOR | 1002-1034 | |
| 29 | 07822-00423 | TUBE | 1002-1034 | |
| 30 | 411-04-11320 | TEE | 1002-1034 | |
| 31 | 07213-50510 | CONNECTOR | 1002-1034 | |
| 32 | 411-04-11231 | TUBE | 1002-1034 | |
| 33 | 281-35-19530 | TEE | 1002-1034 | |
| 34 | 07822-00406 | TUBE | 1002-1034 | |
| 35 | 07822-00431 | TUBE | 1002-1034 | |
| 36 | 08036-02514 | CLIP | 1002-@ | |
| 37 | 154-04-12460 | CLAMP | 1013-@ | |
| 38 | 07270-01210 | TUBE | 1013-@ | |
| 39 | 6721-71-9780 | ADAPTER | 1013-@ | |
| 40 | 285-04-11210 | NIPPLE | 1013-@ |
