| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 565-04-11114 | TANK | 1424- | |
| 1 | 565-04-11113 | TANK | 1256-1423 | |
| 1 | 565-04-11112 | TANK | 935-1255 | |
| 1 | (\2\565-04-11111) | TANK | (935-1147) | |
| 1 | 565-04-11110 | TANK | 510-934 | |
| 2 | 07050-21200 | CAP | 935- | |
| 2 | 07050-11200 | CAP | 510-934 | |
| 3 | 07056-18416 | STRAINER | 510- | |
| 3 | (\2\07056-08420) | STRAINER | (510-1255) | |
| 4 | 07057-04087 | RING | 510-1423 | |
| 5 | 565-04-11221 | TUBE | 935-1423 | |
| 5 | 565-04-11220 | TUBE | 510-677 | |
| 6 | 565-04-11311 | PLATE | 935-1423 | |
| 6 | 565-04-11310 | PLATE | 510-677 | |
| 7 | 566-04-11154 | GAUGE UNIT | 1424- | |
| 7 | 566-04-11153 | GAUGE UNIT | 510-1423 | |
| 8 | 01252-30620 | BOLT | 1424- | |
| 8 | 01010-31025 | BOLT | 510-1423 | |
| 9 | 01602-00619 | WASHER | 1424- | |
| 9 | 01602-01030 | WASHER | 510-1423 | |
| 10 | 07000-03045 | O-RING | 1424- | |
| 10 | 07000-02085 | O-RING | 510-1423 | |
| 565-04-11212 | BRACKET | 678- | ||
| (\2\565-04-11211) | BRACKET | (678-1147) | ||
| 565-04-11210 | BRACKET | 510-677 | ||
| 11 | 565-04-11540 | CUSHION | 1256- | |
| 11 | 565-04-11540 | CUSHION | 1148-1255 | |
| 11 | 565-04-11520 | CUSHION | 1148- | |
| 11 | 565-04-11520 | CUSHION | 510-1147 | |
| 12 | 565-04-11610 | CUSHION | 510- | |
| 565-04-11501 | BAND ASS'Y | 582- | ||
| \0\565-04-11500 | BAND ASS'Y | 510-581 | ||
| 13 | 565-04-11512 | BAND | 582- | |
| 13 | 565-04-11511 | BAND | 510-581 | |
| 14 | 565-04-11520 | CUSHION | 510- | |
| 15 | 565-04-11530 | T-BOLT | 510-581 | |
| 16 | 560-04-11540 | SPRING | 510- | |
| 17 | 01580-01210 | NUT | 510- | |
| 18 | 01604-01223 | WASHER | 510- | |
| 565-44-12700 | VALVE ASS'Y | 1424- | ||
| \0\560-04-11031 | VALVE ASS'Y | 510-1423 | ||
| 19 | 560-04-11411 | BODY | 510-1423 | |
| 20 | 560-04-11421 | COCK | 510-1423 | |
| 20A | 565-44-12700 | VALVE ASS'Y | 1424- | |
| 21 | 07325-00400 | NIPPLE | 1424- | |
| 21 | 565-04-11170 | NIPPLE | 510-1423 | |
| 22 | 07700-20504 | VALVE | 510- | |
| 23 | 07214-61521 | CONNECTOR | 510-934 | |
| 24 | 07217-61521 | ELBOW | 1256- | |
| 24 | 07217-61521 | ELBOW | 935-1255 | |
| 24 | 07217-61521 | ELBOW | 510-934 | |
| 25 | 07102-20419 | HOSE | 935- | |
| 25 | 07100-20415 | HOSE | 510-934 | |
| 25A | 07100-20404 | HOSE | 1256- | |
| 26 | 08036-02514 | CLIP | 1256- | |
| 26 | 08036-02514 | CLIP | 510-1255 | |
| 26 | (\2\04434-02408) | CLIP | (510-1255) | |
| 27 | 01010-31016 | BOLT | 1256- | |
| 27 | 01010-30812 | BOLT | 510-1255 | |
| 28 | 01602-01030 | WASHER | 1256- | |
| 28 | 01602-00825 | WASHER | 510-1255 | |
| 29 | 01010-31435 | BOLT | 510-725 | |
| 30 | 01580-01411 | NUT | 510-725 | |
| 31 | 01602-01442 | WASHER | 510-725 | |
| 32 | 02010-20622 | BOLT | 1256- | |
| 32 | 01010-51025 | BOLT | 726-1255 | |
| 32 | 01010-31020 | BOLT | 510-725 | |
| 33 | 01602-00929 | WASHER | 1256- | |
| 33 | 01602-21030 | WASHER | 726-1255 | |
| 33 | 01602-21030 | WASHER | 510-725 | |
| 34 | 01010-31425 | BOLT | 510-725 | |
| 35 | 01602-01442 | WASHER | 510-725 | |
| 35 | 01643-21032 | WASHER | 726-1255 | |
| 36 | 01010-31025 | BOLT | 1256- | |
| 36 | 01010-31020 | BOLT | 510-1255 | |
| 37 | 01602-01030 | WASHER | 510- | |
| 37A | 01642-01016 | WASHER | 1256- | |
| 38 | (565-04-11701) | TANK ASS'Y,FLOAT | 1256- | |
| 38 | (565-04-11700) | TANK ASS'Y,FLOAT | 702-1255 | |
| 38 | \6\ | TANK ASS'Y,FLOAT | 510-701 | |
| 39 | 08036-11214 | CLIP | 1256- | |
| 39 | 08036-10814 | CLIP | 726-1255 | |
| 39 | 08036-10610 | CLIP | 510-725 | |
| 40 | 01010-30816 | BOLT | 510-1255 | |
| 41 | 01602-00825 | WASHER | 510-1255 | |
| 42 | 08036-11214 | CLIP | 1256- | |
| 42 | 04435-00808 | CLIP | 726-1255 | |
| 42 | 08036-11210 | CLIP | 510-725 | |
| 42A | 560-44-13550 | RING | 726-1255 | |
| 43 | 02750-03210 | HOSE | 1256- | |
| 43 | 02750-03195 | HOSE | 510-1255 | |
| 44 | 02750-04030 | HOSE | 1256- | |
| 44 | 02750-04050 | HOSE | 510-1255 | |
| 44A | 6710-71-8470 | ELBOW | 1256- | |
| 45 | 08037-05022 | GROMMET | 1256- | |
| 45 | 08037-03620 | GROMMET | 510-1255 | |
| 46 | 6686-73-9551 | HOSE | 510-725 | |
| 46 | 02750-04180 | HOSE | 1256- | |
| 46 | 02750-04210 | HOSE | 726-1255 | |
| 47 | 07822-00431 | TUBE | 1424- | |
| 47 | 565-04-71311 | TUBE | 935-1423 | |
| 47 | 565-04-71310 | TUBE | 726-934 | |
| 47 | 565-04-12210 | TUBE | 558-725 | |
| 47 | 560-04-12230 | TUBE | 510-557 | |
| 48 | 565-04-71321 | TUBE | 935- | |
| 48 | 565-04-71320 | TUBE | 726-934 | |
| 48 | 565-04-12220 | TUBE | 558-725 | |
| 48 | 560-04-12210 | TUBE | 510-725 | |
| 49 | 6610-81-8820 | ELBOW | 558-1423 | |
| 49 | 6610-01-3290 | CONNECTOR | 510-557 | |
| 50 | 6610-81-3711 | TEE | 558-1423 | |
| 50 | 6610-81-3710 | TEE | 510-557 | |
| 51 | 07822-00425 | TUBE | 1424- | |
| 51 | 565-04-71311 | TUBE | 935-1423 | |
| 51 | 565-04-71310 | TUBE | 726-934 | |
| 51 | 565-04-12210 | TUBE | 558-725 | |
| 51 | 560-04-12220 | TUBE | 510-557 | |
| 52 | 6610-81-3501 | HAND PRIMER ASS'Y | 510- | |
| 53 | 07202-00508 | NUT | 510-557 | |
| 54 | 560-44-13550 | RING | 726-1255 | |
| 55 | 568-03-12240 | CLIP | 726-1255 | |
| 56 | 01010-50816 | BOLT | 726-1255 | |
| 57 | 01602-20825 | WASHER | 726-1255 | |
| 58 | 560-41-17130 | CLIP | 726-1255 | |
| 59 | 01010-50825 | BOLT | 726-1255 | |
| 60 | 01580-11210 | NUT | 726-1255 | |
| 61 | 01602-20825 | WASHER | 726-1255 | |
| 62 | 08036-02514 | CLIP | 1256- | |
| 62 | 08036-02514 | CLIP | 726-1255 | |
| 63 | 01010-31016 | BOLT | 1256- | |
| 63 | 01010-30812 | BOLT | 726-1255 | |
| 64 | 01602-01030 | WASHER | 1256- | |
| 64 | 01602-00825 | WASHER | 726-1255 | |
| 65 | 131-04-54130 | ELBOW | 935-1423 | |
| 66 | 154-04-12460 | CLAMP | .-1423 | |
| 66 | \0\566-04-11180 | CLIP | 935-. | |
| 67 | 565-04-11261 | ELBOW | 1088-1255 | |
| 67 | 565-04-11260 | ELBOW | 935-1087 | |
| 68 | 565-04-11280 | JOINT | 1088-1255 | |
| 69 | 07002-12434 | O-RING | 1088-1255 | |
| 70 | 07239-12410 | NUT | 1088-1255 | |
| 71 | 565-04-11420 | TUBE | 1124-1255 | |
| 72 | 154-04-12510 | CASE | 1256- | |
| 73 | 154-04-12531 | STRAINER | 1256- | |
| 74 | 07000-03040 | O-RING | 1256- | |
| 75 | 01010-30825 | BOLT | 1256- | |
| 76 | 01580-00806 | NUT | 1256- | |
| 77 | 01602-00825 | WASHER | 1256- | |
| 78 | 01642-20810 | WASHER | 1256- | |
| 79 | 07214-61521 | CONNECTOR | 1256- | |
| 80 | 07822-00817 | TUBE | 1424- | |
| 80 | 07822-00814 | TUBE | 1256-1423 | |
| 281-35-19350 | ELBOW | 1256- | ||
| 81 | 07834-00817 | ELBOW | 1256- | |
| 82 | 07831-00813 | SLEEVE | 1256- | |
| 83 | 07832-00817 | NUT | 1256- | |
| 281-35-19310 | ELBOW | 1424- | ||
| 84 | 07834-00410 | ELBOW | 1424- | |
| 85 | 07831-00411 | SLEEVE | 1424- | |
| 86 | 07832-00410 | NUT | 1424- | |
| 87 | 411-04-11320 | TEE | 1424- | |
| 88 | 07213-50510 | CONNECTOR | 1424- | |
| 281-35-19360 | CONNECTOR | 1424- | ||
| 89 | 07836-00410 | CONNECTOR | 1424- | |
| 90 | 07831-00411 | SLEEVE | 1424- | |
| 91 | 07832-00410 | NUT | 1424- | |
| 92 | 565-44-15331 | JOINT | 1424- |
