| Item | Part No. | Part Name | Qty | Serial No. |
| 154-04-00011 | FUEL TANK ASS'Y | 10009-10010 | ||
| 154-04-00011 | FUEL TANK ASS'Y | 10007-10007 | ||
| 154-04-00011 | FUEL TANK ASS'Y | 10005-10005 | ||
| 1 | 154-04-11115 | TANK | 10009-10010 | |
| 1 | 154-04-11115 | TANK | 10007-10007 | |
| 1 | 154-04-11115 | TANK | 10005-10005 | |
| 2 | 150-54-17190 | PLATE, MARK | 10000-10000 | |
| 2 | 154-54-12521 | PLATE, MARK | 10001-@ | |
| 3 | 150-54-17126 | PLATE, MARK | 10000-10000 | |
| 3 | 154-54-12532 | PLATE, MARK | 10001-@ | |
| 4 | 09652-00100 | PLATE, CAUTION | 10001-@ | |
| 5 | 150-98-11170 | CHART, LUBRICATION | 10000-10000 | |
| 5 | 154-98-11150 | CHART, OIL | 10001-@ | |
| 6 | 01040-62050 | BOLT | 10001-@ | |
| 7 | 01602-12060 | WASHER | 10001-@ | |
| 8 | 01640-12032 | WASHER | 10001-@ | |
| 9 | 154-04-11131 | GAUGE | 10001-10010 | |
| 10 | 130-04-11120 | STRAINER | 1001-@ | |
| 11 | 110-04-11120 | RING | 4001-@ | |
| 12 | 07043-00211 | PLUG | 10009-10010 | |
| 12 | 07043-00211 | PLUG | 10007-10007 | |
| 12 | 07043-00211 | PLUG | 10005-10005 | |
| 07050-00000 | CAP | 10001-@ | ||
| 13 | 07050-00001 | BODY | 10001-@ | |
| 14 | 07050-00002 | GASKET (KIT) | 10001-@ | |
| 154-04-00030 | VALVE ASS'Y | 10001-10010 | ||
| 15 | 154-04-11180 | FLANGE | 10001-@ | |
| 16 | 07000-03035 | O-RING (KIT) | 10001-@ | |
| 17 | 01040-41235 | BOLT | 10001-@ | |
| 18 | 01602-11236 | WASHER | 10001-@ | |
| 19 | 150-04-12122 | VALVE | 1401-10010 | |
| 20 | 150-04-12180 | SLEEVE | 10001-@ | |
| 21 | 150-04-12211 | CLIP | 6371-@ | |
| 22 | 150-04-12190 | TUBE | 1401-@ | |
| 23 | 154-04-11210 | CLIP | 10001-@ | |
| 154-04-00050 | FLANGE ASS'Y | 10001-10010 | ||
| 24 | 154-04-11160 | FLANGE | 10001-@ | |
| 25 | 01040-41235 | BOLT | 10001-@ | |
| 26 | 01602-11236 | WASHER | 10001-@ | |
| 27 | 07000-03035 | O-RING (KIT) | 10001-@ | |
| 28 | 150-04-12240 | JOINT,EYE | 6001-@ | |
| 29 | 07003-02733 | GASKET (KIT) | 4001-@ | |
| 30 | 150-04-12250 | BOLT | 6001-@ | |
| 31 | 150-04-12122 | VALVE | 1401-10010 | |
| 32 | 154-04-11150 | NIPPLE (KIT) | 10001-@ | |
| 154-04-00070 | STRAINER ASS'Y (KIT) | 10001-@ | ||
| 33 | 154-04-11170 | BRACKET | 10001-@ | |
| 34 | 01040-41225 | BOLT | 10001-@ | |
| 35 | 01602-11236 | WASHER | 10001-@ | |
| 36 | 01000-40825 | BOLT | 6001-@ | |
| 37 | 01641-10812 | WASHER | 6001-@ | |
| 38 | 01602-10825 | WASHER | 6001-@ | |
| 39 | 01500-10807 | NUT | 6001-@ | |
| 40 | 154-04-12510 | CASE | 10001-@ | |
| 41 | \6\ | STRAINER | 10001-@ | |
| 41 | \6\ | CAP | 10001-@ | |
| 41 | 150-04-11170 | SCREEN | 6001-@ | |
| 42 | 07000-03040 | O-RING | 10001-@ | |
| 43 | 07000-03032 | O-RING | 6001-@ | |
| 44 | 150-04-11180 | ELBOW | 6001-@ | |
| 154-04-00090 | HOSE ASS'Y | 10009-10010 | ||
| 154-04-00090 | HOSE ASS'Y | 10007-10007 | ||
| 154-04-00090 | HOSE ASS'Y | 10005-10005 | ||
| 45 | 6641-71-8860 | CONNECTOR | 10009-10010 | |
| 45 | 6641-71-8860 | CONNECTOR | 10007-10007 | |
| 45 | 6641-71-8860 | CONNECTOR | 10005-10005 | |
| 46 | 154-04-12330 | HOSE | 10009-10010 | |
| 46 | 154-04-12330 | HOSE | 10007-10007 | |
| 46 | 154-04-12330 | HOSE | 10005-10005 | |
| 47 | 154-04-12350 | HOSE | 10009-10010 | |
| 47 | 154-04-12350 | HOSE | 10007-10007 | |
| 47 | 154-04-12350 | HOSE | 10005-10005 | |
| 48 | 154-04-12370 | HOSE | 10009-10010 | |
| 48 | 154-04-12370 | HOSE | 10007-10007 | |
| 48 | 154-04-12370 | HOSE | 10005-10005 | |
| 154-04-00110 | CLAMP ASS'Y | 10009-10010 | ||
| 154-04-00110 | CLAMP ASS'Y | 10007-10007 | ||
| 154-04-00110 | CLAMP ASS'Y | 10005-10005 | ||
| 49 | 154-04-12390 | PLATE | 10009-10010 | |
| 49 | 154-04-12390 | PLATE | 10007-10007 | |
| 49 | 154-04-12390 | PLATE | 10005-10005 | |
| 50 | 01040-41230 | BOLT | 10009-10010 | |
| 50 | 01040-41230 | BOLT | 10007-10007 | |
| 50 | 01040-41230 | BOLT | 10005-10005 | |
| 51 | 01602-11236 | WASHER | 10009-10010 | |
| 51 | 01602-11236 | WASHER | 10007-10007 | |
| 51 | 01602-11236 | WASHER | 10005-10005 | |
| 154-04-00210 | CLAMP ASS'Y | 10005-10005 | ||
| 154-04-00210 | CLAMP ASS'Y | 10007-10007 | ||
| 154-04-00210 | CLAMP ASS'Y | 10009-10010 | ||
| 52 | \6\ | CLAMP | 10009-10010 | |
| 52 | \6\ | CLAMP | 10007-10007 | |
| 52 | \6\ | CLAMP | 10005-10005 | |
| 53 | \6\ | TUBE | 10009-10010 | |
| 53 | \6\ | TUBE | 10007-10007 | |
| 53 | \6\ | TUBE | 10005-10005 | |
| 154-04-00230 | CLAMP ASS'Y | 10001-@ | ||
| 54 | \6\ | CLAMP | 10001-@ | |
| 55 | \6\ | TUBE | 10001-@ | |
| 56 | 01040-41220 | BOLT | 10009-10010 | |
| 56 | 01040-41220 | BOLT | 10007-10007 | |
| 56 | 01040-41220 | BOLT | 10005-10005 | |
| 57 | 01602-11236 | WASHER | 10009-10010 | |
| 57 | 01602-11236 | WASHER | 10007-10007 | |
| 57 | 01602-11236 | WASHER | 10005-10005 | |
| 154-04-00250 | CLAMP ASS'Y | 10001-@ | ||
| 58 | \6\ | CLAMP | 10001-@ | |
| 59 | \6\ | TUBE | 10001-@ | |
| 60 | 01040-41220 | BOLT | 10001-@ | |
| 61 | 01602-11236 | WASHER | 10001-@ | |
| 154-04-00130 | BRACKET ASS'Y | 10009-10010 | ||
| 154-04-00130 | BRACKET ASS'Y | 10007-10007 | ||
| 154-04-00130 | BRACKET ASS'Y | 10005-10005 | ||
| 62 | 154-04-12440 | BRACKET | 10009-10010 | |
| 62 | 154-04-12440 | BRACKET | 10007-10007 | |
| 62 | 154-04-12440 | BRACKET | 10005-10005 | |
| 63 | 01040-41225 | BOLT | 10009-10010 | |
| 63 | 01040-41225 | BOLT | 10007-10007 | |
| 63 | 01040-41225 | BOLT | 10005-10005 | |
| 64 | 01602-11236 | WASHER | 10009-10010 | |
| 64 | 01602-11236 | WASHER | 10007-10007 | |
| 64 | 01602-11236 | WASHER | 10005-10005 | |
| 65 | 01040-41080 | BOLT | 10009-10010 | |
| 65 | 01040-41080 | BOLT | 10007-10007 | |
| 65 | 01040-41080 | BOLT | 10005-10005 | |
| 66 | 01601-11025 | WASHER | 10009-10010 | |
| 66 | 01601-11025 | WASHER | 10007-10007 | |
| 66 | 01601-11025 | WASHER | 10005-10005 | |
| 67 | 01503-41008 | NUT | 10009-10010 | |
| 67 | 01503-41008 | NUT | 10007-10007 | |
| 67 | 01503-41008 | NUT | 10005-10005 |
