| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 01010-81030 | Bolt | 75384- | |
| 2 | 01643-31032 | Washer | 75384- | |
| 3 | 02782-10314 | Elbow | 75384- | |
| 4 | 02782-10313 | Elbow | 75384- | |
| 5 | 07002-11823 | O-ring | 75384- | |
| 6 | 07002-11823 | O-ring | 75384- | |
| 7 | 02896-11009 | O-ring | 75384- | |
| 8 | 02896-11009 | O-ring | 75384- | |
| 9 | 07270-00820 | Tube | 75384- | |
| 10 | 07270-00820 | Tube | 75384- | |
| 11 | 07285-00115 | Clip | 75384- | |
| 12 | 07285-00115 | Clip | 75384- |
- Главная
- Каталог запчастей
- Колесные погрузчики
- Wa250 6 s/n 75053 up
- Fuel system
- Fuel tank, mounting (2/3) (#75384 )
