| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 7861-93-4930 | Sensor, Fuel Level | 30001- | |
| 2 | 07000-12085 | O-ring | 30001- | |
| 3 | 01010-81020 | Bolt | 30001- | |
| 4 | 01643-31032 | Washer | 30001- | |
| 5 | 04434-50510 | Clip | 30001- | |
| 6 | 01010-81016 | Bolt | 30001- | |
| 7 | 01643-31032 | Washer | 30001- | |
| 8 | 13Y-54-11750 | Seal | 30001- | |
| 9 | 13Y-54-11730 | Seal | 30001- | |
| 10 | 13Y-54-11681 | Seal | 30001- | |
| 11 | 13Y-54-11910 | Seal | 30001- | |
| 12 | 13Y-54-11483 | Seal | 30001- | |
| 13 | 13Y-54-11631 | Seal | 30001- | |
| 14 | 13Y-54-11580 | Seal | 30001- | |
| 15 | 13Y-54-11470 | Seal | 30001- | |
| 22U-04-21241 | Strainer Assembly | 30001- | ||
| 22U-04-21200 | Float Assembly | 30001- | ||
| 16 | Guide | 30001- | ||
| 17 | 20Y-04-21580 | Cap | 30001- | |
| 18 | 22U-04-21220 | Float | 30001- | |
| 19 | Screw | 30001- | ||
| 20 | 07056-18425 | Strainer | 30001- | |
| 21 | 02782-10522 | Elbow | 30001- | |
| 22 | 02896-11015 | O-ring | 30001- | |
| 23 | 07002-12434 | O-ring | 30001- | |
| 24 | 13Y-04-11271 | Bracket | 30001- | |
| 25 | 01010-82065 | Bolt | 30001- | |
| 26 | 01010-82055 | Bolt | 30001- | |
| 27 | 01010-82045 | Bolt | 30001- | |
| 28 | 01643-32060 | Washer | 30001- | |
| 29 | 17A-04-41440 | Lock | 30001- | |
| 30 | 21J-46-12550 | Cap | 30001- |
