| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07102-20623 | HOSE | 1256- | |
| 2 | 6672-52-9931 | ELBOW | 1256- | |
| 3 | 02010-20725 | BOLT | 1256- | |
| 4 | 01602-01134 | WASHER | 1256- | |
| 5 | 07102-20318 | HOSE | 1256- | |
| 6 | 07102-20325 | HOSE | 1256- | |
| 7 | 567-01-12140 | ELBOW | 1256- | |
| 8 | 482-04-31990 | ELBOW | 1256- | |
| 9 | 281-01-17480 | ELBOW | 1256- | |
| 10 | 01010-30820 | BOLT | 1256- | |
| 11 | 01602-00825 | WASHER | 1256- | |
| 12 | 568-03-12240 | CLIP | 1256- | |
| 13 | 01010-31225 | BOLT | 1256- | |
| 13A | 01016-31250 | BOLT | 1424- | |
| 01010-31225 | BOLT | 1256-1423 | ||
| 14 | 01602-01236 | WASHER | 1256- | |
| 15 | 560-41-17130 | CLIP | 1256- | |
| 16 | 01010-31020 | BOLT | 1256- | |
| 17 | 01602-01030 | WASHER | 1256- | |
| 18 | 281-06-16760 | BAND | 1256- | |
| 19 | 08036-02514 | CLIP | 1256- |
