| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 42U-17-12A10 | BRACKET | ||
| 2 | 01435-01225 | SCREW | ||
| 3 | 42U-17-12A90 | CONNECTOR | ||
| 4 | 01252-70622 | SCREW | ||
| 5 | 423-00-H2210 | LOCK WASHER | ||
| 6 | 01580-10605 | NUT | ||
| 7 | 42U-17-12190 | VALVE | ||
| VALVE | ||||
| 8 | 423-09-H3200 | SPRING WASHER | ||
| 9 | 01252-70545 | SCREW | ||
| 10 | 421-00-H0150 | STUD | ||
| 11 | 42Y-00-H1530 | STUD | ||
| 12 | 421-00-H0240 | UNION | ||
| 13 | 421-00-H0480 | UNION | ||
| 14 | 42U-00-H0610 | HOSE ASSEMBLY | ||
| 15 | 42U-00-H0600 | HOSE ASSEMBLY | ||
| 16 | 419-N24-H450 | HOSE ASSEMBLY | ||
| 17 | 42U-00-H0140 | HOSE ASSEMBLY | ||
| 18 | 42Y-00-H2760 | STUD | ||
| 19 | 42U-09-H2010 | HOSE ASSEMBLY | ||
| 20 | 421-00-H0240 | UNION | ||
| 21 | 42U-17-12A20 | BRACKET | ||
| 22 | 42Y-06-H1200 | SWITCH | ||
| 23 | 42U-17-12A30 | COVERING | ||
| 24 | 01641-20405 | PLAIN WASHER | ||
| 25 | 42U-09-H2130 | SCREW | ||
| 26 | 42U-06-12260 | HARNESS | ||
| 27 | 421-00-H0260 | BRACE |
