| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | WB0252 | FITTING - 90 DEG | ||
| 2 | HA1178 | HOSE | ||
| 3 | HA3159 | HOSE | ||
| 4 | C0315 | FITTING, GREASE | ||
| 5 | HA1416 | HOSE | ||
| 6 | VN9907 | CLAMP | ||
| 7 | TG9225 | LOCKNUT - 3/8" - 16NC | ||
| 8 | WB0454 | FITTING, STRAIGHT | ||
| 9 | WB0454 | FITTING, STRAIGHT | ||
| 10 | HA4954 | HOSE | ||
| 11 | WB0252 | FITTING - 90 DEG | ||
| 12 | TZ9844 | BRACKET | ||
| 13 | C1612 | CAPSCREW - 1/2" - 13NC X 1" | ||
| 14 | C1540 | LOCKWASHER - 1/2" | ||
| 14 | C1523 | NUT - 1/2" - 13NC |
