| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 8248-54-1410 | FRAME | 1002-@ | |
| 2 | 01010-81225 | BOLT | 1002-@ | |
| 3 | 01643-31232 | WASHER | 1002-@ | |
| 4 | 8248-54-1430 | FRAME | 1002-1100 | |
| 5 | 01010-81230 | BOLT | 1002-@ | |
| 6 | 01643-31232 | WASHER | 1002-@ | |
| 7 | 8248-54-1422 | FRAME | 1006-@ | |
| 7 | 8248-54-1421 | FRAME | 1002-1005 | |
| 8 | 01010-81225 | BOLT | 1002-@ | |
| 9 | 01643-31232 | WASHER | 1002-@ | |
| 10 | 8248-54-1461 | HAND RAIL | 1002-@ | |
| 11 | 01010-81230 | BOLT | 1002-@ | |
| 12 | 01643-31232 | WASHER | 1002-@ | |
| 13 | 8248-54-1441 | HAND RAIL | 1002-1100 | |
| 14 | 8248-54-1451 | HAND RAIL | 1002-@ | |
| 15 | 01010-81240 | BOLT | 1002-@ | |
| 16 | 01643-31232 | WASHER | 1002-@ | |
| 17 | 8248-54-2110 | BRACKET | 1002-@ | |
| 18 | 01010-81225 | BOLT | 1002-@ | |
| 19 | 01643-31232 | WASHER | 1002-@ | |
| 20 | 8248-54-1481 | HAND RAIL | 1002-@ | |
| 21 | 01010-81240 | BOLT | 1002-@ | |
| 22 | 01643-31232 | WASHER | 1002-@ | |
| 23 | 8248-54-1473 | HAND RAIL | 1006-@ | |
| 23 | 8248-54-1472 | HAND RAIL | 1002-1005 | |
| 24 | 01010-81220 | BOLT | 1002-@ |
