| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 8233-54-1331 | COVER | 1002- | |
| 2 | 01010-51230 | BOLT | 1002- | |
| 3 | 01643-31232 | WASHER | 1002- | |
| 4 | 8233-54-1321 | COVER | 1002- | |
| 5 | 01010-51230 | BOLT | 1002- | |
| 6 | 01643-31232 | WASHER | 1002- | |
| 7 | 8233-54-1312 | COVER | 1008- | |
| 7 | 8233-54-1311 | COVER | 1002-1007 | |
| 8 | 01010-51230 | BOLT | 1002- | |
| 9 | 01643-31232 | WASHER | 1002- | |
| 10 | 8233-54-1212 | BOX | 1008- | |
| 10 | 8233-54-1211 | BOX | 1002-1007 | |
| 11 | 01010-51230 | BOLT | 1002- | |
| 12 | 01643-31232 | WASHER | 1002- | |
| 13 | 8233-54-1241 | COVER | 1008- | |
| 13 | 8233-54-1240 | COVER | 1002-1007 | |
| 14 | 01010-51030 | BOLT | 1002- | |
| 15 | 01643-31032 | WASHER | 1002- | |
| 16 | 569-54-61480 | ROD | 1002- | |
| 17 | 01643-31032 | WASHER | 1002- | |
| 18 | 04050-13020 | PIN | 1002- | |
| 19 | 09450-00000 | CATCH | 1002- | |
| 20 | 09450-00002 | PIN | 1002- | |
| 21 | 04050-11610 | PIN | 1002- | |
| 22 | 8233-54-1480 | COVER | 1002- | |
| 23 | 01010-51225 | BOLT | 1002- | |
| 24 | 01643-31232 | WASHER | 1002- | |
| 25 | 8233-54-1351 | COVER | 1002- | |
| 26 | 01010-51230 | BOLT | 1002- | |
| 27 | 01643-31232 | WASHER | 1002- | |
| 28 | 8233-54-1341 | COVER | 1002- | |
| 29 | 01010-51230 | BOLT | 1002- | |
| 30 | 01643-31232 | WASHER | 1002- | |
| 31 | 8233-54-1030 | STEP | 1002- | |
| 32 | 01010-51230 | BOLT | 1002- | |
| 33 | 01643-31232 | WASHER | 1002- | |
| 34 | 8229-54-1050 | HAND RAIL | 1002- | |
| 35 | 01010-51030 | BOLT | 1002- | |
| 36 | 01643-31032 | WASHER | 1002- | |
| 37 | 8233-54-1290 | HANDLE | 1002- | |
| 38 | 01010-51030 | BOLT | 1002- | |
| 39 | 01643-31032 | WASHER | 1002- |
