| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 56B-43-17714 | TUBE | ||
| 2 | 56B-43-17724 | TUBE | ||
| 3 | 02896-21009 | O-RING | ||
| 4 | 04434-51510 | CLIP | ||
| 5 | 01010-81020 | BOLT | ||
| 6 | 01643-31032 | WASHER | ||
| 7 | 516-61-12320 | CLAMP | ||
| 8 | 01643-51032 | WASHER | ||
| 9 | 01010-81035 | BOLT | ||
| 10 | 01643-31032 | WASHER | ||
| 11 | 02766-00310 | HOSE | ||
| 12 | 56B-43-27690 | BRACKET | ||
| 13 | 01010-81025 | BOLT | ||
| 14 | 01643-31032 | WASHER | ||
| 15 | 56B-43-27790 | BRACKET | ||
| 16 | 01010-81025 | BOLT | ||
| 17 | 01643-31032 | WASHER | ||
| 18 | 08036-03014 | CLIP | ||
| 19 | 07095-00316 | CUSHION | ||
| 20 | 01435-01020 | BOLT |
