| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 425-877-4211 | TUBE | ||
| 2 | 425-877-4221 | TUBE | ||
| 3 | 07000-B3035 | O-RING | ||
| 4 | 07372-21040 | BOLT | ||
| 5 | 01643-51032 | WASHER | ||
| 6 | 425-877-3231 | PLATE | ||
| 7 | 419-43-17920 | WASHER | ||
| 8 | 417-62-14130 | SPACER | ||
| 9 | 415-64-13130 | CUSHION | ||
| 10 | 419-43-17930 | CUSHION | ||
| 11 | 419-43-17920 | WASHER | ||
| 12 | 01010-81250 | BOLT | ||
| 13 | 07283-53444 | SEAT | ||
| 14 | 07283-33450 | CLIP | ||
| 15 | 01643-31032 | WASHER | ||
| 16 | 22P-70-12160 | NUT | ||
| 17 | 425-877-3290 | PLATE | ||
| 18 | 419-43-17920 | WASHER | ||
| 19 | 417-62-14130 | SPACER | ||
| 20 | 415-64-13130 | CUSHION | ||
| 21 | 419-43-17930 | CUSHION | ||
| 22 | 419-43-17920 | WASHER | ||
| 23 | 01010-81250 | BOLT | ||
| 24 | 07283-53444 | SEAT | ||
| 25 | 07283-33450 | CLIP | ||
| 26 | 01643-31032 | WASHER | ||
| 27 | 22P-70-12160 | NUT | ||
| 28 | HOSE, FLANGE TYPE (SEE FIG. T4110-005003 ) |
