| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 09482-10000 | Valve, Water | 1006- | |
| 2 | 154-911-8170 | Hose Assembly | 1006- | |
| 3 | 09479-02400 | Clip | 1006- | |
| 4 | 281-81-12930 | Joint | 1006- | |
| 5 | 04434-53212 | Clip | 1006- | |
| 6 | 07095-20523 | Cushion | 1006- | |
| 7 | 20Y-03-11220 | Collar | 1006- | |
| 8 | 01010-81075 | Bolt | 1006- | |
| 9 | 01643-31032 | Washer | 1006- | |
| 10 | 154-911-8180 | Hose Assembly | 1006- | |
| 11 | 09479-02400 | Clip | 1006- | |
| 12 | 09484-00560 | Connector | 1006- | |
| 13 | 09483-70550 | Hose | 1006- | |
| 14 | 09479-02400 | Clip | 1006- | |
| 15 | 154-911-8190 | Bracket | 1006- | |
| 16 | 04434-53412 | Clip | 1006- | |
| 17 | 07095-20625 | Cushion | 1006- | |
| 18 | 01010-81230 | Bolt | 1006- | |
| 19 | 01643-31232 | Washer | 1006- | |
| 20 | (154-03-71711) | Tube | - |
