| Item | Part No. | Part Name | Qty | Serial No. |
| 561-63-22600 | CYLINDER ASS'Y | 1501- | ||
| 1 | 561-63-22640 | CYLINDER | 1501- | |
| 2 | 569-63-22880 | BUSHING | 1501- | |
| 3 | 04071-00130 | RING,SNAP | 1501- | |
| 4 | 561-63-22740 | HEAD,CYLINDER | 1501- | |
| 5 | 581-63-92670 | SEAL,DUST | 1501- | |
| 6 | 561-63-22680 | PLATE | 1501- | |
| 7 | 707-51-20250 | PACKING,ROD | 1501- | |
| 8 | 581-63-22291 | BUSHING | 1501- | |
| 9 | 07000-15220 | O-RING | 1501- | |
| 10 | 07001-05220 | RING,BACK-UP | 1501- | |
| 11 | 01011-82010 | BOLT | 1501- | |
| 12 | 01602-22060 | WASHER,SPRING | 1501- | |
| 13 | 561-63-22660 | CYLINDER | 1501- | |
| 14 | 561-63-22770 | RING,SNAP | 1501- | |
| 15 | 581-63-22581 | RING,WEAR | 1501- | |
| 16 | 707-51-16550 | PACKING,ROD | 1501- | |
| 17 | 707-52-11650 | BUSHING | 1501- | |
| 18 | 707-56-16550 | SEAL,DUST | 1501- | |
| 19 | 707-75-10050 | RING,SNAP | 1501- | |
| 20 | 561-63-22670 | CYLINDER | 1501- | |
| 21 | 561-63-22780 | RING,SNAP | 1501- | |
| 22 | 07155-01845 | RING,WEAR | 1501- | |
| 23 | 707-51-11110 | PACKING,ROD | 1501- | |
| 24 | 07177-01140 | BUSHING | 1501- | |
| 25 | 198-63-94170 | SEAL,DUST | 1501- | |
| 26 | 07179-00135 | RING,SNAP | 1501- | |
| 27 | 561-63-22620 | ROD,PISTON | 1501- | |
| 28 | 569-63-22880 | BUSHING | 1501- | |
| 29 | 04071-00130 | RING,SNAP | 1501- | |
| 30 | 07020-00675 | FITTING,GREASE | 1501- | |
| 31 | 707-36-14560 | PISTON | 1501- | |
| 32 | 707-44-14080 | RING,PISTON | 1501- | |
| 33 | 07155-01435 | RING,WEAR | 1501- | |
| 34 | 01124-82255 | STUD | 1501- | |
| 35 | 07165-12222 | NUT,NYLON | 1501- |
