| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-61-13110 | TUBE | 1002- | |
| 2 | 569-61-13120 | TUBE | 1002- | |
| 3 | 07000-13048 | O-RING | 1069- | |
| \0\07000-23048 | O-RING | 1002-1068 | ||
| 4 | 07372-21245 | BOLT | 1002- | |
| 5 | 01602-21236 | WASHER | 1002- | |
| 6 | 07114-01408 | HOSE | 1002- | |
| 7 | 07371-31465 | FLANGE | 1069- | |
| \0\07371-21465 | FLANGE | 1002-1068 | ||
| 8 | 07372-21240 | BOLT | 1002- | |
| 9 | 01602-21236 | WASHER | 1002- | |
| 10 | 07000-13048 | O-RING | 1069- | |
| \0\07000-23048 | O-RING | 1002-1068 | ||
| 11 | 569-61-13340 | BRACKET | 1002- | |
| 12 | 01010-51225 | BOLT | 1002- | |
| 13 | 01602-21236 | WASHER | 1002- | |
| 14 | 07283-24949 | CLIP | 1002- | |
| 15 | 01599-01011 | NUT | 1002- | |
| 16 | 01643-31032 | WASHER | 1002- | |
| 17 | 569-61-13320 | JOINT | 1002- | |
| 18 | 01011-51205 | BOLT | 1002- | |
| 19 | 01602-21236 | WASHER | 1002- | |
| 20 | 569-61-13130 | TUBE | 1002- | |
| 569-61-13140 | TUBE | 1002-1068 | ||
| 21 | 569-61-13141 | TUBE | 1069- | |
| 22 | 07371-31255 | FLANGE | 1069- | |
| \0\07371-21255 | FLANGE | 1002-1068 | ||
| 23 | 07372-21035 | BOLT | 1002- | |
| 24 | 01602-21030 | WASHER | 1002- | |
| 25 | 07000-13038 | O-RING | 1069- | |
| \0\07000-23038 | O-RING | 1002-1068 | ||
| 26 | 569-61-13152 | TUBE | 1069- | |
| 569-61-13151 | TUBE | 1002-1068 | ||
| 27 | 569-61-13162 | TUBE | 1069- | |
| 569-61-13161 | TUBE | 1002-1068 | ||
| 28 | 07371-30500 | FLANGE | 1069- | |
| \0\07371-20500 | FLANGE | 1002-1068 | ||
| 29 | 07372-20830 | BOLT | 1002- | |
| 30 | 01602-20825 | WASHER | 1002- | |
| 31 | 07000-13022 | O-RING | 1069- | |
| \0\07000-23022 | O-RING | 1002-1068 | ||
| 32 | 07283-22236 | CLIP | 1002- | |
| 33 | 07283-23442 | CLIP | 1002- | |
| 34 | 01599-01011 | NUT | 1002- | |
| 35 | 01643-31032 | WASHER | 1002- | |
| 36 | 569-61-13370 | PLATE | 1002- | |
| 37 | 569-61-13381 | BRACKET | 1069- | |
| 569-61-13380 | BRACKET | 1002-1068 | ||
| 38 | 569-61-13391 | BRACKET | 1069- | |
| 569-61-13390 | BRACKET | 1002-1068 | ||
| 39 | 01010-51225 | BOLT | 1002- | |
| 40 | 01602-21236 | WASHER | 1002- | |
| 41 | 07118-01208 | HOSE | 1069- | |
| 07115-41207 | HOSE | 1002-1068 | ||
| 42 | 07118-40507 | HOSE | 1002- | |
| 43 | 07371-31255 | FLANGE | 1069- | |
| \0\37371-21255 | FLANGE | 1002-1068 | ||
| 44 | 07372-21035 | BOLT | 1002- | |
| 45 | 01602-21030 | WASHER | 1002- | |
| 46 | 07000-13038 | O-RING | 1069- | |
| \0\07000-23038 | O-RING | 1002-1068 | ||
| 47 | 07371-30500 | FLANGE | 1069- | |
| \0\07371-20500 | FLANGE | 1002-1068 | ||
| 48 | 07372-20830 | BOLT | 1002- | |
| 49 | 01602-20825 | WASHER | 1002- | |
| 50 | 07000-13022 | O-RING | 1069- | |
| \0\07000-23022 | O-RING | 1002-1068 | ||
| 51 | 569-61-13170 | TUBE | 1002-1068 | |
| 52 | 569-61-13180 | TUBE | 1002- | |
| 53 | 07000-13035 | O-RING | 1069- | |
| \0\07000-23035 | O-RING | 1002-1068 | ||
| 54 | 01011-51010 | BOLT | 1002-1068 | |
| 55 | 01011-51005 | BOLT | 1002-1068 | |
| 56 | 01602-21030 | WASHER | 1002- | |
| 57 | 07042-20108 | PLUG | 1002-1068 | |
| 58 | 566-61-13390 | ELBOW | 1002- | |
| 59 | 07000-13022 | O-RING | 1069- | |
| \0\07000-23022 | O-RING | 1002-1068 | ||
| 60 | 01010-50860 | BOLT | 1002- | |
| 61 | 01602-20825 | WASHER | 1002- | |
| 62 | 07042-20108 | PLUG | 1002- | |
| 63 | 569-61-13410 | STEP | 1002- | |
| 64 | 569-61-13420 | STEP | 1002- | |
| 65 | 01010-51240 | BOLT | 1002- | |
| 66 | 01602-21236 | WASHER | 1002- |
