| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | HA7454 | HOSE | ||
| 2 | TH5602 | CLAMP, HALF | ||
| 3 | TH5601 | GROMMET | ||
| 4 | C7591 | CAPSCREW - 1/4" - 20NC X 2" | ||
| 5 | C5774 | LOCKWASHER - 1/4" | ||
| 6 | HA7339 | HOSE | ||
| 7 | TF3231 | CLAMP, SPLIT FLANGE - 2" | ||
| 8 | C1540 | LOCKWASHER - 1/2" | ||
| 9 | C1614 | CAPSCREW - 1/2" - 13NC X 1 1/2" | ||
| 10 | WA0187 | O-RING | ||
| 11 | WB0996 | FLANGE, SPLIT SWIVEL | ||
| 12 | XB3937 | FILTER ASSEMBLY (SEE INDEX) |
