| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | (363-60-32100) | VALVE ASS'Y | 23973- | |
| 1 | (415-17-13100) | VALVE ASS'Y | 23001-23972 | |
| 2 | 01252-30840 | BOLT | 23001- | |
| 3 | 363-18-31553 | TUBE | 23001- | |
| 4 | 07260-02620 | HOSE | 23668- | |
| 4 | 07260-02618 | HOSE | 23001-23667 | |
| 5 | 07289-00045 | CLAMP | 23668- | |
| 5 | 07281-00489 | CLAMP | 23001-23667 | |
| 6 | 07000-13032 | O-RING | 23001- | |
| 7 | 01435-01025 | BOLT | 23001- | |
| 8 | 363-18-31420 | TUBE | 23001- | |
| 9 | 198-09-31210 | CLAMP | 23668- | |
| 9 | 07281-00259 | CLAMP | 23001-23667 | |
| 10 | 363-18-31571 | HOSE | 23001- | |
| 12 | 363-18-32121 | ELBOW | 23001- | |
| 13 | 07040-11007 | PLUG | 23001- | |
| 14 | 07002-11023 | O-RING | 23001- | |
| 15 | 416-62-11240 | UNION | 23001- | |
| 16 | 416-62-11490 | ELBOW | 23001- | |
| 17 | 416-62-11480 | O-RING | 23001- | |
| 18 | 363-18-32230 | HOSE | 23001- | |
| 19 | 363-18-32111 | HOSE | 23001- | |
| 20 | 363-18-33111 | HOSE | 23001- | |
| 21 | 363-18-33211 | HOSE | 23042- | |
| 21 | 363-18-33210 | HOSE | 23001-23041 | |
| 22 | 363-18-35110 | PROTECTOR | 23042- | |
| 23 | 415-62-13710 | PROTECTOR | 23001- | |
| 24 | 363-18-33141 | TEE | 23001- | |
| 25 | 20D-62-17150 | O-RING | 23001- | |
| 26 | 198-09-31210 | CLAMP | 23543- | |
| 26 | 07281-00259 | CLAMP | 23001-23542 | |
| 27 | 363-18-33151 | BRACKET | 23001- | |
| 28 | 01435-01020 | BOLT | 23001- | |
| 29 | 04434-52510 | CLIP | 23001- | |
| 30 | 01435-01016 | BOLT | 23001- | |
| 31 | 08034-20536 | BAND | 23001- |
