| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | HA6769 | HOSE | ||
| 2 | HA7385 | HOSE | ||
| 3 | HA6766 | HOSE | ||
| 4 | HA7334 | HOSE | ||
| 5 | HA5768 | HOSE | ||
| 6 | HA6502 | HOSE | ||
| 7 | EC1221 | BRACKET | ||
| 8 | TY8375 | SPACER | ||
| 9 | MM0016 | CAPSCREW - M8 X 1.25 X 16 | ||
| 10 | MM0470 | LOCKWASHER - M8 | ||
| 11 | MM0460 | FLAT WASHER - M8 | ||
| 12 | MM0177 | NUT - M8 X 1.25 | ||
| 13 | VN9913 | CLAMP, VINYL - 1 1/16" | ||
| 14 | WB0375 | FITTING, 90 DEG ELBOW - 37 DEG FLARE | ||
| 15 | HA7369 | HOSE | ||
| 16 | HA7782 | HOSE | ||
| 17 | TG2960 | CLAMP, VINYL - 9/16" | ||
| 18 | TG2568 | CLAMP, VINYL - 7/8" | ||
| 19 | TR9441 | CLAMP, VINYL - 1 1/4" | ||
| 20 | EF7303 | BRACKET, HOSE | ||
| 21 | C0312 | LOCKWASHER - 3/8" | ||
| 22 | C1521 | NUT - 3/8" - 16NC | ||
| 23 | EF7305 | BRACKET, HOSE |
