| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 426-62-23681 | PLATE | 50001- | |
| 2 | 01435-01020 | BOLT | 50001- | |
| 3 | 426-62-23780 | RUBBER | 50001- | |
| 4 | 419-43-17910 | SPACER | 50001- | |
| 5 | 426-62-23790 | PLATE | 50001- | |
| 6 | 01435-01050 | BOLT | 50001- | |
| 7 | 426-62-23671 | TUBE | 50001- | |
| 8 | 04434-51510 | CLIP | 50001- | |
| 9 | 01435-01020 | BOLT | 50001- | |
| 10 | 01435-01016 | BOLT | 50001- | |
| 11 | 426-62-24240 | ELBOW | .- | |
| 11 | 419-62-23860 | ELBOW | 50001-. | |
| 12 | 07002-12034 | O-RING | 50001- | |
| 13 | 07042-70108 | PLUG | .- | |
| 13 | 07042-70108 | PLUG | 50001-. | |
| 14 | 426-62-23641 | TUBE | 50001- | |
| 15 | 04434-51510 | CLIP | 50001- | |
| 16 | 07283-31537 | CLIP | 50001- | |
| 17 | 01643-30823 | WASHER | 50001- | |
| 18 | 01596-00807 | NUT | 50001- | |
| 19 | 07102-20307 | HOSE | 50001- | |
| 20 | 04434-51810 | CLIP | 50001- | |
| 21 | 426-62-24240 | ELBOW | .- | |
| 21 | 421-62-18150 | ELBOW | 50001-. | |
| 22 | 07002-12034 | O-RING | 50001- | |
| 23 | 07042-70108 | PLUG | .- | |
| 23 | 07042-70108 | PLUG | 50001-. | |
| 24 | 426-62-23661 | TUBE | 50001- | |
| 25 | 04434-51510 | CLIP | 50001- | |
| 26 | 426-62-23651 | TUBE | 50001- | |
| 27 | 04434-51510 | CLIP | 50001- | |
| 28 | 04435-51510 | CLIP | 50001- | |
| 29 | 01435-01020 | BOLT | 50001- |
