| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-61-44121 | TUBE | 1102- | |
| 2 | 569-61-44131 | TUBE | 1102- | |
| 3 | 07235-50522 | ELBOW | 1102- | |
| 4 | 07002-12434 | O-RING | 1102- | |
| 5 | 07042-20108 | PLUG | 1102- | |
| 6 | 566-61-44540 | PLATE | 1102- | |
| 7 | 07283-22236 | CLIP | 1102- | |
| 8 | 01643-31032 | WASHER | 1102- | |
| 9 | 01599-01011 | NUT | 1102- | |
| 10 | 07088-00507 | HOSE | 1102- | |
| 11 | 07371-30500 | FLANGE | 1102- | |
| 12 | 07000-23022 | O-RING | 1102- | |
| 13 | 01010-50830 | BOLT | 1102- | |
| 14 | 01602-20825 | WASHER | 1102- | |
| 15 | 569-61-44540 | BLOCK | 1102- | |
| 16 | 01010-51230 | BOLT | 1102- | |
| 17 | 01602-21236 | WASHER | 1102- | |
| 18 | 07087-00505 | HOSE | 1102- | |
| 19 | 569-61-44550 | FLANGE | 1102- | |
| 20 | 07000-23032 | O-RING | 1102- | |
| 21 | 01252-40830 | BOLT | 1102- | |
| 22 | 01602-20825 | WASHER | 1102- | |
| 23 | 569-61-43112 | TUBE | 1242- | |
| 24 | 07000-23038 | O-RING | 1102- | |
| 25 | 07372-21030 | BOLT | 1102- | |
| 26 | 01602-21030 | WASHER | 1102- | |
| 27 | 07087-41407 | HOSE | 1242- | |
| 28 | 07371-31465 | FLANGE | 1242- | |
| 29 | 07372-21240 | BOLT | 1242- | |
| 30 | 01602-21236 | WASHER | 1242- | |
| 31 | 07000-23048 | O-RING | 1242- | |
| 32 | 569-61-43122 | TUBE | 1242- | |
| 33 | 07000-23038 | O-RING | 1102- | |
| 34 | 07372-21035 | BOLT | 1102- | |
| 35 | 01602-21030 | WASHER | 1102- | |
| 36 | 569-61-43521 | BRACKET | 1242- | |
| 37 | 01010-51030 | BOLT | 1102- | |
| 38 | 01643-31032 | WASHER | 1102- | |
| 39 | 01602-21030 | WASHER | 1102- | |
| 40 | 07283-24354 | CLIP | 1102- | |
| 41 | 01643-31032 | WASHER | 1102- | |
| 42 | 01599-01011 | NUT | 1102- | |
| 43 | 07298-01007 | HOSE | 1242- | |
| 44 | 07371-31049 | FLANGE | 1102- | |
| 45 | 07372-21035 | BOLT | 1242- | |
| 46 | 01602-21030 | WASHER | 1102- | |
| 47 | 07000-23032 | O-RING | 1102- | |
| 48 | 569-61-48131 | TUBE | 1242- | |
| 49 | 07000-23038 | O-RING | 1102- | |
| 50 | 07372-21035 | BOLT | 1102- | |
| 51 | 01602-21030 | WASHER | 1102- | |
| 52 | 07000-23048 | O-RING | 1102- | |
| 53 | 07372-21240 | BOLT | 1102- | |
| 54 | 01602-21236 | WASHER | 1102- | |
| 55 | 569-61-48141 | TUBE | 1242- | |
| 56 | 07000-23050 | O-RING | 1102- | |
| 57 | 01010-51435 | BOLT | 1102- | |
| 58 | 01602-21442 | WASHER | 1102- | |
| 59 | 569-61-48511 | BRACKET | 1242- | |
| 60 | 01010-51230 | BOLT | 1242- | |
| 61 | 01602-21236 | WASHER | 1242- | |
| 62 | 01643-31232 | WASHER | 1242- | |
| 63 | 07100-20305 | HOSE | 1102- | |
| 64 | 566-35-14340 | NIPPLE | 1102- | |
| 65 | 566-35-14350 | ELBOW | 1102- | |
| 66 | 281-62-19470 | BAND | 1102- | |
| 67 | 569-61-44530 | BAND | 1102- | |
| 68 | 01010-51030 | BOLT | 1102- | |
| 69 | 01580-11008 | NUT | 1102- | |
| 70 | 01602-21030 | WASHER | 1102- | |
| 71 | 569-61-44560 | HOSE | 1102- | |
| 72 | 07371-30500 | FLANGE | 1102- | |
| 73 | 01010-50830 | BOLT | 1102- | |
| 74 | 01602-20825 | WASHER | 1102- | |
| 75 | 07000-23022 | O-RING | 1102- |
