| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 428-62-13640 | TUBE | 10001- | |
| 2 | 07000-F2060 | O-RING | 10001- | |
| 3 | 01435-01270 | BOLT | 10001- | |
| 4 | 01435-01285 | BOLT | 10001- | |
| 5 | 07114-02016 | HOSE | 10001- | |
| 6 | 07000-12060 | O-RING | 10001- | |
| 7 | 07371-32076 | FLANGE,SPLIT | 10001- | |
| 8 | 07372-21240 | BOLT | 10001- | |
| 9 | 01643-51232 | WASHER | 10001- | |
| 10 | 428-62-14121 | TUBE | 10001- | |
| 11 | 07000-F2060 | O-RING | 10001- | |
| 12 | 07372-21240 | BOLT | 10001- | |
| 13 | 01643-51232 | WASHER | 10001- | |
| 14 | 428-62-13722 | PLATE | 10055- | |
| \0\428-62-13721 | PLATE | 10018-10054 | ||
| \0\428-62-13720 | PLATE | 10001-10017 | ||
| 15 | 01435-01240 | BOLT | 10001- | |
| 16 | 07283-36163 | CLIP | 10018- | |
| 07283-36163 | CLIP | 10001-10017 | ||
| 17 | 01597-01009 | NUT | 10018- | |
| 01597-01009 | NUT | 10001-10017 | ||
| 18 | 01643-31032 | WASHER | 10018- | |
| 01643-31032 | WASHER | 10001-10017 | ||
| 19 | 428-62-13833 | PLATE | 10055- | |
| 428-62-13832 | PLATE | 10018-10054 | ||
| \0\428-62-13831 | PLATE | 10001-10017 | ||
| 20 | 01010-81030 | BOLT | 10018- | |
| 01010-81020 | BOLT | 10001-10017 | ||
| 21 | 01643-31032 | WASHER | 10018- | |
| 01643-31032 | WASHER | 10001-10017 | ||
| 22 | 07283-36163 | CLIP | 10018- | |
| 07283-36163 | CLIP | 10001-10017 | ||
| 23 | 426-09-11160 | NUT | 10018- | |
| 426-09-11160 | NUT | 10001-10017 | ||
| 24 | 01643-31032 | WASHER | 10018- | |
| 01643-31032 | WASHER | 10001-10017 | ||
| 25 | 07283-56170 | SEAT | 10018- | |
| 26 | 07283-56170 | SEAT | 10018- |
