| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 567-61-12342 | TUBE | 1113- | |
| 1 | 567-61-12341 | TUBE | 1002-1112 | |
| 2 | 07000-23032 | O-RING | 1002- | |
| 3 | 07372-21030 | BOLT | 1002- | |
| 4 | 01602-01030 | WASHER | 1002- | |
| 5 | 07118-01008 | HOSE | 1002- | |
| 6 | 07000-23032 | O-RING | 1002- | |
| 7 | 07371-01044 | FLANGE | 1002- | |
| 8 | 07372-21030 | BOLT | 1002- | |
| 9 | 07372-21035 | BOLT | 1002- | |
| 10 | 01602-01030 | WASHER | 1002- | |
| 11 | 567-61-12391 | TUBE | 1002- | |
| 12 | 07000-23048 | O-RING | 1002- | |
| 13 | 07000-23035 | O-RING | 1002- | |
| 14 | 07372-21245 | BOLT | 1002- | |
| 15 | 01602-01236 | WASHER | 1002- | |
| 16 | 01010-31055 | BOLT | 1002- | |
| 17 | 01010-31050 | BOLT | 1002- | |
| 18 | 01602-01030 | WASHER | 1002- | |
| 19 | 567-61-12350 | ELBOW | 1002- | |
| 20 | 07000-23035 | O-RING | 1002- | |
| 21 | 01010-31085 | BOLT | 1002- | |
| 22 | 01602-01030 | WASHER | 1002- | |
| 23 | 567-61-12370 | TUBE | 1002- | |
| 24 | 07000-23035 | O-RING | 1002- | |
| 25 | 01010-31060 | BOLT | 1002- | |
| 26 | 01010-31055 | BOLT | 1002- | |
| 27 | 01602-01030 | WASHER | 1002- | |
| 28 | 07260-23210 | HOSE | 1002- | |
| 29 | 07281-00489 | CLAMP | 1002- | |
| 30 | 567-61-12380 | TUBE | 1002- | |
| 31 | 01010-31050 | BOLT | 1002- | |
| 32 | (567-60-11001) | TANK ASS'Y,(SEE FIG.611) | 1002- | |
| 33 | 567-60-12112 | BRACKET | 1216- | |
| 33 | 567-60-12113 | BRACKET | 1215-1215 | |
| 33 | 567-60-12112 | BRACKET | 1002-1214 | |
| 34 | 567-60-12122 | BRACKET | 1216- | |
| 34 | 567-60-12123 | BRACKET | 1215-1215 | |
| 34 | 567-60-12122 | BRACKET | 1002-1214 | |
| 35 | 01010-31435 | BOLT | 1002- | |
| 36 | 01602-01442 | WASHER | 1002- | |
| (567-64-12000) | VALVE ASS'Y,DEMAND (SEE FIG.625) | 1002-. | ||
| 37 | (567-64-12001) | VALVE ASS'Y,DEMAND (SEE FIG.625) | .- | |
| 38 | 567-60-12150 | PLATE | 1002- | |
| 39 | 01010-31430 | BOLT | 1002- | |
| 40 | 01602-01442 | WASHER | 1002- | |
| 41 | 01010-31225 | BOLT | 1002- | |
| 42 | 01602-01236 | WASHER | 1002- |
