| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 417-62-33172 | TUBE | B10001- | |
| 2 | 417-62-33181 | TUBE | B10001- | |
| 3 | 02789-00628 | O-RING | B10001- | |
| 4 | 02896-11015 | O-RING | B10001- | |
| 5 | 02789-10628 | PLUG | B10001- | |
| 6 | 07283-32236 | CLIP | B10001- | |
| 7 | 01597-01009 | NUT | B10001- | |
| 8 | 01643-31032 | WASHER | B10001- | |
| 9 | 07283-52232 | SEAT | B10001- | |
| 10 | 417-62-33281 | BRACKET {L.H.} | B10523- | |
| \0\417-62-33280 | BRACKET {L.H.} | B10001-B10522 | ||
| 11 | 417-62-33291 | BRACKET {R.H.} | B10523- | |
| \0\417-62-33290 | BRACKET {R.H.} | B10001-B10522 | ||
| 12 | 415-64-13130 | CUSHION | B10001- | |
| 13 | 419-43-17930 | CUSHION | B10001- | |
| 14 | 417-54-13470 | SPACER | B10001- | |
| 15 | 415-64-13120 | WASHER | B10001- | |
| 16 | 01010-81060 | BOLT | B10001- | |
| 17 | 01643-31032 | WASHER | B10001- |
