| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 417-T90-3222 | TUBE,R.H. | A89001- | |
| 2 | 417-T90-3212 | TUBE,L.H. | A89001- | |
| 3 | 417-T90-3262 | PLATE | A89001- | |
| 4 | 415-64-13120 | WASHER | A89001- | |
| 5 | 419-43-17930 | CUSHION | A89001- | |
| 6 | 417-62-14130 | SPACER | A89001- | |
| 7 | 415-64-13130 | CUSHION | A89001- | |
| 8 | 01010-81045 | BOLT | A89001- | |
| 9 | 417-T90-3751 | PLATE | A89001- | |
| 10 | 417-T90-3761 | PLATE | A89001- | |
| 11 | 415-64-13120 | WASHER | A89001- | |
| 12 | 419-43-17930 | CUSHION | A89001- | |
| 13 | 417-62-14130 | SPACER | A89001- | |
| 14 | 415-64-13130 | CUSHION | A89001- | |
| 15 | 01010-81045 | BOLT | A89001- | |
| 16 | 415-64-13120 | WASHER | A89001- | |
| 17 | 417-T90-3440 | WASHER | A89001- | |
| 18 | 419-43-17930 | CUSHION | A89001- | |
| 19 | 417-62-14130 | SPACER | A89001- | |
| 20 | 415-64-13130 | CUSHION | A89001- | |
| 21 | 01010-81055 | BOLT | A89001- | |
| 22 | 417-T90-3272 | PLATE,L.H. | A89001- | |
| 23 | 417-T90-3190 | PLATE,R.H. | A89001- | |
| 24 | 01010-81025 | BOLT | A89001- | |
| 25 | 01643-31032 | WASHER | A89001- | |
| 26 | 07283-32746 | CLIP | A89001- | |
| 27 | 07283-52737 | SEAT | A89001- | |
| 28 | 01643-31032 | WASHER | A89001- | |
| 29 | 01597-01009 | NUT | A89001- | |
| 30 | 417-T90-3252 | HOSE | A89001- | |
| 31 | 07000-13025 | O-RING | A89001- | |
| 32 | 07371-30640 | FLANGE | A89001- | |
| 33 | 07372-21035 | BOLT | A89001- | |
| 34 | 01643-51032 | WASHER | A89001- | |
| 35 | 417-T90-3291 | BRACKET | A89001- | |
| 36 | 01010-81020 | BOLT | A89001- | |
| 37 | 01643-31032 | WASHER | A89001- | |
| 38 | 07094-10620 | CLAMP | A89001- | |
| 39 | 07095-00628 | CUSHION | A89001- | |
| 40 | 01010-81270 | BOLT | A89001- | |
| 41 | 01643-31232 | WASHER | A89001- | |
| 42 | BLOCK,(SEE FIG. T4121-01A0) | A89001- | ||
| 43 | BLOCK,(SEE FIG. T4121-01A0) | A89001- |
