Item | Part No. | Part Name | Qty | Serial No. |
1 | 103-30-24160 | PISTON | 61132- | |
2 | 09370-00040 | U-PACKING | 61132- | |
3 | 04064-02512 | RING,SNAP | 61132- | |
4 | 07155-00410 | RING,WEAR | 61132- | |
5 | 103-30-34230 | BAR | 61132- | |
6 | 103-30-34570 | PLATE | 61132- | |
7 | 01010-81650 | BOLT | 61132- | |
8 | 01643-31645 | WASHER | 61132- | |
9 | 103-30-34580 | CYLINDER | 61132- | |
10 | 103-30-24250 | SPACER | 61132- | |
11 | 07177-04025 | BUSHING | 61132- | |
12 | 103-30-24240 | SEAL,DUST | 61132- | |
13 | 04065-05220 | RING,SNAP | 61132- | |
14 | 103-30-34540 | PLATE | 61132- | |
15 | 01010-80830 | BOLT | 61132- | |
16 | 01602-20825 | WASHER,SPRING | 61132- | |
17 | 203-30-42260 | VALVE | 61132- | |
18 | 103-30-34550 | NUT | 61132- | |
19 | 07020-00900 | FITTING,GREASE | 61132- | |
20 | 103-30-34421 | SPRING | 61182- | |
20 | 103-30-34420 | SPRING | 61132-61181 | |
21 | 103-30-34511 | BRACKET,L.H. | 61132- | |
103-30-34521 | BRACKET,R.H. | 61132- | ||
22 | 01010-81630 | BOLT | 61132- | |
23 | 01643-31645 | WASHER | 61132- |
