| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 14X-30-13113 | CYLINDER | 3001- | |
| 2 | 07177-09040 | BUSHING | 3001- | |
| 3 | 207-30-54140 | SPRING | 3001- | |
| 4 | 14Y-30-11373 | CABIN | 3001- | |
| 5 | 208-30-54160 | NUT | 3001- | |
| 6 | 14X-30-13240 | SPACER | 3001- | |
| 7 | 14X-30-13250 | SPACER | 3001- | |
| 8 | 203-30-42260 | VALVE | 3001- | |
| 9 | 07020-00900 | FITTING | 3001- | |
| 10 | 14X-30-13174 | PLATE | 3001- | |
| 11 | 01010-50830 | BOLT | 3001- | |
| 12 | 01643-30823 | WASHER | 3001- | |
| 13 | 14X-30-13163 | HOLDER | 3001- | |
| 14 | 07177-09040 | BUSHING | 3001- | |
| 15 | 07019-00090 | SEAL | 3001- | |
| 16 | 135-30-14620 | COVER | 3001- | |
| 17 | 01010-51020 | BOLT | 3001- | |
| 18 | 01643-31032 | WASHER | 3001- | |
| 19 | 04530-11018 | BOLT | 3001- | |
| 20 | 07000-06235 | O-RING | 3001- | |
| 21 | 01010-51235 | BOLT | 3001- | |
| 22 | 01643-31232 | WASHER | 3001- | |
| 23 | 14X-30-13142 | PISTON | 3001- | |
| 24 | 150-30-13442 | PACKING | 3001- | |
| 25 | 150-30-13480 | RING | 3001- | |
| 26 | 150-30-13460 | RING,SNAP | 3001- | |
| 27 | 150-30-13430 | RING | 3001- | |
| 28 | 14X-30-13124 | YOKE | 3001- | |
| 29 | 195-30-14151 | WASHER | 3001- | |
| 30 | 195-30-14160 | PLATE | 3001- | |
| 31 | 01010-52460 | BOLT | 3001- | |
| 32 | 01010-52070 | BOLT | 3001- | |
| 33 | 01643-32060 | WASHER | 3001- |
