| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 562-97-13510 | PANEL | 1501- | |
| 2 | 09415-03614 | CAP | 1501- | |
| 3 | 195-06-23110 | GAUGE,WATER TEMPERATURE | 1501- | |
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 4 | 565-06-13131 | SPEEDOMETER | 1501- | |
| 562-06-15610 | METER | 1501- | ||
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 5 | 566-06-17151 | LAMP,TURN | 1546- | |
| 08147-42461 | LAMP,TURN | 1501-1545 | ||
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 6 | 566-06-17141 | LAMP,HIGH BEAM | 1546- | |
| 08147-42460 | LAMP,HIGH BEAM | 1501-1545 | ||
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 7 | 195-06-23140 | AMMETER | 1501- | |
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 8 | 566-06-41112 | GAUGE,OIL PRESSURE | 1501- | |
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 9 | 566-06-15840 | TACHOMETER | 1501- | |
| 08111-02430 | BULB¤ 3W,3W | 1501- | ||
| 10 | 562-97-13520 | PANEL | 1501- | |
| 11 | 195-06-23120 | GAUGE,OIL TEMPERATURE | 1501- | |
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 12 | 512-06-11420 | GAUGE,AIR PRESSURE | 1501- | |
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 13 | 566-06-41350 | LAMP,KICK-DOWN | 1546- | |
| 566-43-41321 | LAMP,KICK-DOWN | 1501-1545 | ||
| 08111-02430 | BULB¤ 3W,3W | 1501- | ||
| 13A | 09415-01610 | CAP,(WITHOUT KICK-DOWN) | 1501- | |
| 14 | 566-06-17131 | LAMP,RETARDER | 1546- | |
| 08147-42432 | LAMP,RETARDER | 1501-1545 | ||
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 15 | 08147-52430 | LAMP,PARKING | 1501- | |
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 16 | 566-06-15871 | GAUGE | 1501- | |
| 08111-12430 | BULB¤ 3W | 1501- | ||
| 17 | 08687-22403 | METER,SERVICE | 1551- | |
| 566-06-41140 | METER,SERVICE | 1501-1550 | ||
| 18 | 08086-10000 | SWITCH,STARTING | 1501- | |
| 19 | 09415-01610 | CAP | 1501- | |
| 20 | 01225-40616 | SCREW | 1501- | |
| 21 | 581-06-15320 | WASHER | 1501- | |
| 22 | 581-06-15330 | HINGE | 1501- | |
| 23 | 01220-40420 | SCREW | 1501- | |
| 24 | 01580-10403 | NUT | 1501- | |
| 25 | 01601-20410 | WASHER | 1501- | |
| 26 | 09415-01610 | CAP | 1501- | |
| 27 | 562-43-23311 | LAMP,BODY FLOAT | 1546- | |
| 562-43-23310 | LAMP,BODY FLOAT | 1501-1545 | ||
| 08111-02430 | BULB¤ 3W | 1501- | ||
| 28 | 09415-00506 | CAP | 1501- | |
| 29 | 08061-50010 | SWITCH,LIGHT | 1501- | |
| 30 | 09491-00000 | LIGHTER | 1501- | |
| 31 | 566-06-13780 | RESISTOR | 1501- | |
| 32 | 09415-00706 | CAP | 1501- | |
| 33 | 561-06-31111 | CABLE | 1501- | |
| 34 | 561-06-41130 | CABLE | 1501- | |
| 35 | 566-06-16510 | BOX | 1501- | |
| 36 | 01220-40816 | SCREW | 1501- | |
| 37 | 01602-20825 | WASHER | 1501- | |
| 38 | 01641-20812 | WASHER | 1501- | |
| 39 | 566-06-15270 | TUBE | 1501- |
