| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 425-46-36310 | TUBE | A92001-- | |
| 2 | 425-46-36320 | TUBE | A92001-- | |
| 3 | 425-46-36430 | TUBE | A92001-- | |
| 4 | 425-46-36191 | TUBE | A92001-- | |
| 5 | 425-46-36152 | TUBE | A92001-- | |
| 6 | 425-46-36140 | TUBE | A92001-- | |
| 7 | 425-46-36181 | TUBE | A92001-- | |
| 8 | 425-46-36171 | TUBE | A92001-- | |
| 9 | 425-46-36160 | TUBE | A92001-- | |
| 10 | 425-46-36240 | TUBE | A92001-- | |
| 11 | 421-09-12540 | ELBOW | A92001-- | |
| 12 | 423-09-12110 | CONNECTOR | A92001-- | |
| 13 | 04435-50610 | CLIP | A92001-- | |
| 14 | 04434-50612 | CLIP | A92001-- | |
| 15 | 01010-81016 | BOLT | A92001-- | |
| 16 | 01643-31032 | WASHER | A92001-- | |
| 17 | 425-46-36213 | TUBE | A92001-- | |
| 18 | 425-46-36223 | TUBE | A92001-- | |
| 19 | 425-46-36232 | TUBE | A92001-- | |
| 20 | 425-46-36251 | TUBE | A92001-- | |
| 21 | 425-46-36261 | TUBE | A92001-- | |
| 22 | 423-09-12110 | CONNECTOR | A92001-- | |
| 23 | 421-09-12540 | ELBOW | A92001-- | |
| 24 | 04434-50610 | CLIP | A92001-- | |
| 25 | 04435-50610 | CLIP | A92001-- | |
| 26 | 01010-81016 | BOLT | A92001-- | |
| 27 | 01643-31032 | WASHER | A92001-- | |
| 28 | 07020-00000 | FITTING, GREASE | A92001-- | |
| 29 | 07043-70108 | PLUG | A92001-- | |
| 30 | 07020-00000 | FITTING, GREASE | A92001-- | |
| 31 | 426-70-13270 | ELBOW | A92001-- | |
| 32 | 426-70-13291 | HOSE | A92001-- | |
| 33 | 04434-51210 | CLIP | A92001-- | |
| 34 | 01010-81016 | BOLT | A92001-- | |
| 35 | 01643-31032 | WASHER | A92001-- | |
| 36 | 07020-00000 | FITTING, GREASE , | A92001-- |
