| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | TA 4 411 | INJECTOR ASSEMBLY | A50001-- | |
| 2 | 581-96-19620 | CAP | A50001-- | |
| 3 | 427-S95-1660 | CONNECTOR | A50001-- | |
| 4 | 427-S95-2150 | TUBE | A50001-- | |
| 5 | 427-S95-2170 | ELBOW | A50001-- | |
| 6 | 581-96-19580 | NIPPLE | A50001-- | |
| 7 | VW 7 989 | INJECTOR ASSEMBLY | A50001-- | |
| 8 | VW 7 990 | CAP | A50001-- | |
| 9 | 581-96-19590 | PLUG | A50001-- | |
| 10 | 01435-00845 | BOLT | A50001-- | |
| 11 | 427-S95-1870 | TUBE | A50001-- | |
| 12 | 427-S95-1880 | TUBE | A50001-- | |
| 13 | 427-S95-1890 | TUBE | A50001-- | |
| 14 | 427-S95-1910 | TUBE | A50001-- | |
| 15 | 425-S95-2120 | CONNECTOR | A50001-- | |
| 16 | 04434-50610 | CLIP | A50001-- | |
| 17 | 04435-50610 | CLIP | A50001-- | |
| 18 | 01435-01016 | BOLT | A50001-- | |
| 19 | 427-S95-1920 | TUBE | A50001-- | |
| 20 | 427-S95-1930 | TUBE | A50001-- | |
| 21 | 425-S95-2120 | CONNECTOR | A50001-- | |
| 22 | 561-95-63290 | ELBOW | A50001-- | |
| 23 | 07350-00108 | NIPPLE | A50001-- | |
| 24 | 04435-50610 | CLIP | A50001-- | |
| 25 | 01435-01016 | BOLT | A50001-- | |
| 26 | 427-S95-1940 | TUBE | A50001-- | |
| 27 | 427-S95-2430 | UNION | A50001-- | |
| 28 | 561-95-63290 | ELBOW | A50001-- | |
| 29 | 04434-50610 | CLIP | A50001-- | |
| 30 | 01435-01016 | BOLT | A50001-- | |
| 31 | TUBE (SEE FIG. J4710-08A1 ) | A50001-- |
