| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 421-06-45111 | WIRING HARNESS | A45001-- | |
| 2 | 423-06-45120 | WIRING HARNESS | A45001-- | |
| 3 | 423-06-45133 | WIRING HARNESS | A45001-- | |
| 4 | 423-06-45141 | FUSE BOX | A45001-- | |
| N/I | 08044-00010 | TERMINAL | A45001-- | |
| 5 | 423-06-45151 | FUSE BOX | A45001-- | |
| N/I | 08044-00010 | TERMINAL | A45001-- | |
| 6 | 423-06-45161 | WIRING HARNESS | A45001-- | |
| 7 | 419-09-11150 | CLIP | A45001-- | |
| 8 | 234-885-3660 | CLIP | A45001-- | |
| 9 | 01010-81020 | BOLT | A45001-- | |
| 10 | 01643-31032 | WASHER | A45001-- | |
| 11 | 04434-52711 | CLIP | A45001-- | |
| 12 | 22D-62-18450 | SPACER | A45001-- | |
| 13 | 01010-81055 | BOLT | A45001-- | |
| 14 | 01643-31032 | WASHER | A45001-- | |
| 15 | 01010-81025 | BOLT | A45001-- | |
| 16 | 01643-31032 | WASHER | A45001-- | |
| 17 | 04434-51410 | CLIP | A45001-- | |
| 18 | 04434-51510 | CLIP | A45001-- | |
| 19 | 175-79-83760 | SPACER | A45001-- | |
| 20 | 01010-81040 | BOLT | A45001-- | |
| 21 | 01643-31032 | WASHER | A45001-- | |
| 22 | 04434-52310 | CLIP | A45001-- | |
| 23 | 04434-53411 | CLIP | A45001-- | |
| 24 | 560-43-15220 | WASHER | A45001-- | |
| 25 | 01010-81035 | BOLT | A45001-- | |
| 26 | 01643-31032 | WASHER | A45001-- | |
| 27 | 01010-81016 | BOLT | A45001-- | |
| 28 | 01643-31032 | WASHER | A45001-- | |
| 29 | 08059-00310 | CLIP | A45001-- | |
| 30 | 08034-40521 | BAND | A45001-- | |
| 31 | 423-54-42380 | FINISHER | A45001-- | |
| 32 | 423-54-42990 | FINISHER | A45001-- | |
| 33 | WIRING HARNESS (SEE FIG. K4202-10A0) | A45001-- |
