| Item | Part No. | Part Name | Qty | Serial No. |
| 426-S62-2102 | HOSE KIT | A52001-- | ||
| 1 | 426-S62-2131 | HOSE | A52001-- | |
| 2 | 426-S62-2141 | HOSE | A52001-- | |
| 3 | 426-S62-2152 | HOSE | A52001-- | |
| 4 | 426-S62-2161 | HOSE | A52001-- | |
| 5 | 419-S62-2250 | JOINT | A52001-- | |
| 20Y-979-3150 | O-RING | A52001-- | ||
| 6 | 426-S62-2170 | HOSE | A52001-- | |
| 7 | 423-S62-2280 | TUBE | A52001-- | |
| 20Y-979-3150 | O-RING | A52001-- | ||
| 421-07-21810 | SWITCH, PRESSURE | A52001-- | ||
| 421-07-21820 | WIRING HARNESS | A52001-- | ||
| 8 | 423-S62-2290 | TUBE | A52001-- | |
| 20Y-979-3130 | O-RING | A52001-- | ||
| 9 | 426-S62-2350 | BRACKET | A52001-- | |
| 10 | 07283-31529 | CLIP | A52001-- | |
| 11 | 01643-30823 | WASHER | A52001-- | |
| 12 | 01596-00807 | NUT | A52001-- | |
| 13 | 07283-31227 | CLIP | A52001-- | |
| 14 | 01643-30623 | WASHER | A52001-- | |
| 15 | 01596-00606 | NUT | A52001-- | |
| 16 | 01435-00630 | BOLT | A52001-- | |
| 17 | 04435-52210 | CLIP | A52001-- | |
| 18 | 01435-01016 | BOLT | A52001-- | |
| 19 | 427-03-10370 | SPACER | A52001-- | |
| 20 | 01435-01045 | BOLT | A52001-- | |
| 21 | 04434-51910 | CLIP | A52001-- | |
| 22 | 01435-01020 | BOLT | A52001-- | |
| 23 | 04434-51510 | CLIP | A52001-- | |
| 24 | 01435-01016 | BOLT | A52001-- | |
| 25 | 426-S62-2110 | BRACKET | A52001-- | |
| 26 | 01435-01020 | BOLT | A52001-- | |
| 27 | 07283-36155 | CLIP | A52001-- | |
| 28 | 01643-31032 | WASHER | A52001-- | |
| 29 | 01597-01009 | NUT | A52001-- | |
| 30 | 01435-00625 | BOLT | A52001-- | |
| 31 | 01435-00625 | BOLT | A52001-- | |
| 32 | 01643-30623 | WASHER | A52001-- | |
| 33 | 04434-51510 | CLIP | A52001-- | |
| 34 | 01435-01016 | BOLT | A52001-- | |
| 35 | 04435-51610 | CLIP | A52001-- | |
| 36 | 01435-01025 | BOLT | A52001-- | |
| 37 | 08034-20536 | BAND | A52001-- | |
| 38 | 01435-01016 | BOLT | A52001-- | |
| 39 | 01435-00630 | BOLT | A52001-- | |
| 40 | 08036-00814 | BOLT | A52001-- | |
| 41 | 04434-51610 | CLIP | A52001-- | |
| 42 | 01435-01016 | BOLT | A52001-- | |
| 43 | 421-07-23950 | PLATE | A52001-- | |
| 44 | 421-07-23980 | SHEET | A52001-- | |
| 45 | 01435-00610 | BOLT | A52001-- |
