| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | VA1730 | SWITCH | ||
| 2 | TV5194 | FITTING, PIPE | ||
| 3 | VA1733 | MOUNT | ||
| 4 | VA1732 | GASKET | ||
| 5 | VN6448 | CAPSCREW - 5/16" - 18NC X 3/4" | ||
| 6 | C1538 | LOCKWASHER - 5/16" | ||
| 7 | SC4970 | FITTING, PIPE | ||
| 8 | VM5736 | GRIP, CORD | ||
| 9 | TZ7152 | CABLE | ||
| 10 | SP7846 | CLIP | ||
| 11 | WA0192 | WELD STUD - 1/4" - 20NC X 3/4" | ||
| 12 | C5774 | LOCKWASHER - 1/4" | ||
| 13 | C5780 | NUT - 1/4" - 20NC | ||
| 14 | TZ5065 | CABLE | ||
| 14 | VH5017 | TIE STRAP | ||
| 14 | PB6406 | GAUGE CLUSTER (SEE INSTRUMENT PANEL PAGE) |
