| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 421-54-44710 | FENDER, L.H. | A47001-- | |
| 2 | 421-54-44720 | FENDER, R.H. | A47001-- | |
| 3 | 421-54-44730 | SHEET, L.H. | A47001-- | |
| 4 | 421-54-44740 | SHEET, R.H. | A47001-- | |
| 5 | 421-54-44870 | PLATE | A47001-- | |
| 6 | 01010-81025 | BOLT | A47001-- | |
| 7 | (NSS) | WASHER | A47001-- | |
| 8 | 421-54-34550 | WASHER | A47001-- | |
| 9 | 01584-31008 | NUT | A47001-- | |
| 10 | 01010-81230 | BOLT | A47001-- | |
| 11 | 01010-D1225 | BOLT | A47001-- | |
| 12 | 421-03-31590 | WASHER | A47001-- | |
| 13 | 421-54-22990 | PLUG | A47001-- | |
| 14 | 421-54-45270 | BRACKET, L.H. | A47001-- | |
| 15 | 421-54-45280 | BRACKET, R.H. | A47001-- | |
| 16 | 01010-D1250 | BOLT | A47001-- | |
| 17 | 421-03-31590 | WASHER | A47001-- | |
| 18 | 423-54-44150 | CATCH ASSEMBLY | A47001-- | |
| 19 | 01010-80825 | BOLT | A47001-- | |
| 20 | 01643-50823 | WASHER | A47001-- | |
| 21 | 120-01-31321 | PLATE | A47001-- | |
| 22 | 423-54-44130 | HOOK | A47001-- | |
| 23 | 01010-80825 | BOLT | A47001-- | |
| 24 | 01643-50823 | WASHER | A47001-- | |
| 25 | 423-54-34730 | BRACKET | A47001-- | |
| 26 | 423-54-34740 | BRACKET | A47001-- | |
| 27 | 423-54-34780 | CUSHION | A47001-- | |
| 28 | 423-54-44110 | BRACKET | A47001-- | |
| 29 | 01010-D1225 | BOLT | A47001-- | |
| 30 | 01643-31232 | WASHER | A47001-- | |
| 31 | 423-54-44180 | BRACKET | A47001-- | |
| 32 | 203-54-63830 | STOPPER | A47001-- | |
| 33 | 01580-11008 | NUT | A47001-- | |
| 34 | 421-54-44570 | SHEET | A47001-- | |
| 35 | 423-54-44380 | COLLAR | A47001-- | |
| 36 | 01010-81025 | BOLT | A47001-- | |
| 37 | (NSS) | WASHER | A47001-- | |
| 38 | 20Y-54-11611 | STOPPER | A47001-- | |
| 39 | 01580-11008 | NUT | A47001-- | |
| 40 | 01643-31032 | WASHER | A47001-- |
