| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 20Y-54-71211 | FRAME | C62001- | |
| 2 | 20Y-54-74821 | FRAME | C62001- | |
| 3 | 20Y-54-71271 | FRAME | C62001- | |
| 3 | \6\ | FRAME | C62001- | |
| 4 | 20Y-54-61760 | SHEET | C62001- | |
| 5 | 01010-81230 | BOLT | C62001- | |
| 6 | 01643-31232 | WASHER | C62001- |
- Главная
- Каталог запчастей
- Гусеничные экскаваторы
- Pc200 8 s/n c60001 up
- Guard
- Machine cab frame (for pre fuel filter)(#c62001 )
Поиск по каталогу
MACHINE CAB FRAME (FOR PRE-FUEL FILTER)(#C62001-)
