| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | EH4119 | PANEL, DASH - MAIN | | |
| 2 | | SUB PANEL MODULE (SEE FIG 50281) | | |
| 3 | SM0926 | SCREW, PAN HEAD | | |
| 4 | EG3915 | PANEL, DASH - R.H. | | |
| 5 | EG3914 | OVERLAY, LEXAN | | |
| 6 | PC0493 | SWITCH, ROCKER (HAZARD) | | |
| 7 | PC0548 | SWITCH, ROCKER (ASR CUT) | | |
| 8 | SM2717 | LOUVER | | |
| 9 | DC4979 | CLAMP, WORM DRIVE | | |
| 10 | PC0160 | SWITCH, PUSH-PULL | | |
| 11 | WB2488 | DECAL, AUXILIARY BRAKE SWITCH | | |
| 12 | DC9822 | SCREW, DRIVE | | |
| 13 | WB2490 | DECAL, KEY SWITCH WARNING | | |
| 14 | 08086-10000 | SWITCH, STARTER | | |
| 15 | PC0484 | SWITCH, ROCKER (BACKUP LIGHT) | | |
| 16 | TX7829 | SEAL, STEERING COLUMN | | |
| 17 | SM2648 | PLATE, SEAL RETAINER - R.H. | | |
| 18 | SM2646 | PLATE, SEAL RETAINER - L.H. | | |
| 19 | WB2480 | OVERLAY, LEXAN LIGHT SWITCH | | |
| 20 | PC0483 | SWITCH, ROCKER (LADDER LIGHT) | | |
| 21 | PC0481 | SWITCH, ROCKER (HEADLIGHT) | | |
| 22 | SM5060 | DECAL, ENGINE COOLANT LEVEL | | |
| 23 | SM5062 | DECAL, ENGINE OIL TEMPERATURE | | |
| 24 | SM5061 | DECAL, ENGINE OIL PRESSURE | | |
| 25 | SM5059 | DECAL, CRANKCASE BLOWBY PRESSURE | | |
| 26 | SM5053 | DECAL, ACCUMULATOR PRECHARGE PRESSURE | | |
| 27 | SM5065 | DECAL, STEERING SYSTEM PRESSURE | | |
| 28 | SM5064 | DECAL, LATERAL SLOPE WARNING | | |
| 29 | SM5057 | DECAL, BRAKE OIL PRESSURE | | |
| 30 | SM4471 | DECAL, CHECK ENGINE | | |
| 31 | SM5058 | DECAL, BATTERY CHARGE AMP | | |
| 32 | SM5067 | DECAL, TRANSMISSION OIL TEMPERATURE | | |
| 33 | EG4437 | DECAL, TRANSMISSION FILTER | | |
| 34 | EG4434 | DECAL, PARKING BRAKE | | |
| 35 | EG4435 | DECAL, BODY FLOAT | | |
| 36 | SM5056 | DECAL, BRAKE | | |
| 37 | EG4436 | DECAL, MAINTENANCE | | |
| 38 | SM2853 | BRACKET | | |
| 39 | SM2709 | SCREW, FLAT HEAD | | |
| 40 | 569-06-61711 | SWITCH | | |
| 41 | MM0711 | FLAT WASHER - M6 | | |
| 42 | PC0489 | SWITCH, ROCKER (LAMP TEST) | | |
| 43 | EG6162 | LIGHT, WARNING | | |
| 44 | EH4117 | OVERLAY, LEXAN | | |
| 45 | EH4116 | PANEL, DASH - L.H. | | |
| 46 | SM4443 | LENS/FLASHER ASSEMBLY | | |
| 47 | PC0677 | LAMP, LED (RED) | | |
| 48 | PC0551 | LAMP, LED (WHITE) | | |
| 49 | PC0494 | SWITCH, ROCKER (FRONT BRAKE CUT) | | |
| 50 | PC0491 | SWITCH, ROCKER (ENGINE SLOW) | | |
| 51 | PC0492 | SWITCH, ROCKER (ETHER START) | | |
| NS|52 | | NOTE: NS = NOT SHOWN | | |
| NS|53 | EH5033 | HARNESS - MAIN | | |
| NS|54 | EH5032 | HARNESS - R.H. | | |
| NS|55 | EH5031 | HARNESS - L.H. | | |
| NS|56 | 08102-12403 | BULB | | |
