| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 267-10-11102 | FRAME | 1172- | |
| 267-10-11101 | FRAME | 1137-1171 | ||
| 267-10-11100 | FRAME | 1106-1136 | ||
| 267-10-11109 | FRAME | 1067-1105 | ||
| 267-10-11108 | FRAME | 1047-1066 | ||
| 2 | 267-10-15401 | COVER | 1047- | |
| 3 | 01040-01020 | BOLT | 1047- | |
| 4 | 01601-01025 | WASHER | 1047- | |
| 5 | 267-10-15501 | COVER | 1047- | |
| 6 | 01040-01020 | BOLT | 1047- | |
| 7 | 01601-01025 | WASHER | 1047- | |
| 8 | 267-10-15711 | COVER | 1047-1120 | |
| 9 | 01000-00816 | BOLT | 1047-1120 | |
| 10 | 01601-00820 | WASHER | 1047-1120 | |
| 11 | 267-10-15600 | COVER | 1047- | |
| 12 | 01000-00816 | BOLT | 1047- | |
| 13 | 01601-00820 | WASHER | 1047- | |
| 14 | 267-10-12602 | COVER | 1047- | |
| 15 | 267-10-17500 | LOCK | 1047- | |
| 16 | 267-10-17610 | SPRING | 1047- | |
| 17 | 267-10-17620 | COLLAR | 1047- | |
| 18 | 04050-03030 | PIN | 1047- | |
| 19 | 267-10-15302 | PLATE | 1207- | |
| 267-10-15301 | PLATE | 1047-1206 | ||
| 20 | 01040-01022 | BOLT | 1047- | |
| 21 | 01503-01008 | NUT | 1047- | |
| 22 | 01601-01025 | WASHER | 1047- | |
| 23 | 267-10-17101 | PLATE | 1047- | |
| 24 | 01040-01025 | BOLT | 1047- | |
| 25 | 267-10-17310 | WASHER | 1047- | |
| 26 | 267-10-17201 | PLATE | 1047- | |
| 27 | 01040-01025 | BOLT | 1047- | |
| 28 | 267-10-17310 | WASHER | 1047- | |
| 29 | 267-10-14901 | CATCH | 1047- | |
| 30 | 01040-01020 | BOLT | 1047- | |
| 31 | 01601-01025 | WASHER | 1047- | |
| 32 | 267-10-17631 | GUIDE | 1047- | |
| 33 | 01000-01440 | BOLT | 1047- | |
| 34 | 01500-01411 | NUT | 1047- | |
| 35 | 01601-01435 | WASHER | 1047- | |
| 36 | 267-10-15900 | GUARD | 1047- | |
| 37 | 01040-01014 | BOLT | 1047- | |
| 38 | 01601-01025 | WASHER | 1047- | |
| 39 | 267-10-15801 | GUARD | 1047- | |
| 40 | 01040-01020 | BOLT | 1047- | |
| 41 | 01601-01025 | WASHER | 1047- | |
| 42 | 267-10-17641 | HOOK | 1047- | |
| 43 | 01000-01440 | BOLT | 1047- | |
| 44 | 01601-01435 | WASHER | 1047- | |
| 45 | 267-10-15110 | RUBBER | 1047- | |
| 46 | 01220-40516 | SCREW | 1137- | |
| 01220-20516 | SCREW | 1047-1136 | ||
| 47 | 265-04-85000 | NUT | 1137- | |
| 01500-00504 | NUT | 1047-1136 | ||
| 48 | 01642-00508 | WASHER | 1047- | |
| 49 | 01601-00513 | WASHER | 1047- | |
| 50 | 266-90-12100 | MIRROR ASS'Y | 1047- | |
| 51 | 267-90-13130 | PLATE | 1047- | |
| 52 | 04418-03060 | SCREW | 1047- | |
| 53 | 267-90-13150 | PLATE | 1047- | |
| 54 | 267-90-13160 | PLATE | 1067- | |
| 55 | 267-90-13240 | PLATE | 1067- | |
| 56 | 267-10-15721 | COVER | 1067- | |
| 267-10-15720 | COVER | 1047-1066 | ||
| 57 | 01000-20816 | BOLT | 1047- | |
| 58 | 01601-20820 | WASHER | 1047- | |
| 59 | 267-90-13114 | PLATE | 1137- | |
| 267-90-13113 | PLATE | 1097-1136 | ||
| 267-90-13112 | PLATE | 1067-1096 | ||
| 267-90-13111 | PLATE | 1047-1066 | ||
| 60 | 04418-03060 | SCREW | 1067- | |
| 04418-03060 | SCREW | 1047-1066 | ||
| 61 | 267-90-13210 | PLATE | 1047- | |
| 62 | 267-90-13190 | PLATE | 1047- | |
| 63 | 267-90-13220 | PLATE | 1047- | |
| 64 | 267-90-13180 | PLATE | 1047- | |
| 65 | 265-91-12211 | PLATE¤ NAME | 1157- | |
| 265-91-12210 | PLATE¤ NAME | 1047-1156 | ||
| 66 | 04418-03060 | SCREW | 1047- | |
| 67 | 265-91-11210 | PLATE¤ NAME | 1047- | |
| 68 | 04418-03060 | SCREW | 1047- | |
| 69 | 266-90-13280 | PLATE | 1047- | |
| 70 | 266-90-13290 | PLATE | 1047- | |
| 71 | 265-91-51030 | PLATE | 1157- | |
| 72 | 01010-31635 | BOLT | 1172- | |
| 73 | 01602-01648 | WASHER | 1172- |
