| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | BF3897 | FRAME STRUCTURE ASSEMBLY | ||
| 2 | VE4733 | LINE WITH FITTINGS | ||
| 3 | VE4477 | NUT | ||
| 4 | VE4478 | SLEEVE | ||
| 5 | VE4734 | LINE WITH FITTINGS | ||
| 6 | VE4477 | NUT | ||
| 7 | VE4478 | SLEEVE | ||
| 8 | VE4735 | LINE WITH FITTINGS | ||
| 9 | VE4477 | NUT | ||
| 10 | VE4478 | SLEEVE | ||
| 11 | VE4736 | LINE WITH FITTINGS | ||
| 12 | VE4477 | NUT | ||
| 13 | VE4478 | SLEEVE | ||
| 13 | VE4737 | CLAMP | ||
| 14 | TC1234 | CAPSCREW - .31 X 0.75 G5 | ||
| 15 | VE4687 | LOCKWASHER | ||
| 16 | BF3898 | HOSE | ||
| 17 | BF3899 | HOSE | ||
| 18 | VE0670 | CLAMP, HOSE | ||
| 19 | VE2836 | CABLE & CLAMP | ||
| 20 | VE4483 | CLAMP | ||
| 21 | VE3957 | CABLE | ||
| 22 | VE3179 | CLEAT | ||
| 23 | VE3180 | CLAMP | ||
| 24 | VE3181 | BRACKET | ||
| 25 | VE4487 | STRAP | ||
| 26 | VJ1024 | CLAMP | ||
| 27 | VE4488 | SLEEVE | ||
| 28 | VE4489 | BOLT, HEX HEAD | ||
| 29 | VE4490 | WASHER | ||
| 30 | VE4491 | STRAP | ||
| 31 | VE4492 | INSULATION | ||
| 32 | VE4739 | BOLT, HEX HEAD | ||
| 33 | VE4229 | CABLE ASSEMBLY | ||
| 34 | VE4484 | PAD | ||
| 35 | VJ9656 | SEALER - .3 OZ | ||
| 36 | VE6088 | TUBING | ||
| 36 | VE4740 | ADAPTOR | ||
| 37 | VE3919 | SPACER | ||
| 37 | BF1217 | FITTING, 45 DEG | ||
| 38 | BF2610 | CABLE / CONNECTION STRAP | ||
| 39 | VJ6489 | PLUG SPCL | ||
| 40 | VS8047 | PIPE PLUG - 1.25 | ||
| 41 | BF3913 | PLUG MAGNETIC | ||
| 42 | VE4512 | CAP | ||
| 43 | VE8378 | CAP, OIL | ||
| 44 | VE1000 | GASKET, OIL CAP | ||
| 45 | VS8408 | PIN | ||
| 46 | VE1272 | TERMINAL BLOCK | ||
| 47 | TV1918 | CAPSCREW - .50 X 1.75 G5 | ||
| 48 | VE4490 | WASHER | ||
| 49 | TV6025 | CAPSCREW - .25C X 1.5 CAD | ||
| 50 | VJ3550 | WASHER | ||
| 51 | DF3445 | FLAT WASHER - .25 | ||
| 52 | VE2308 | NUT | ||
| 53 | VE7202 | WASHER - .25-SPCL | ||
| 54 | VJ0969 | STRAP | ||
| 55 | VE4750 | INSULATOR WITH STUD | ||
| 56 | TC1233 | NUT, HEX | ||
| 57 | VE4515 | WASHER | ||
| 58 | VE4739 | BOLT, HEX HEAD | ||
| 59 | VE4516 | WASHER | ||
| 60 | VE4687 | LOCKWASHER | ||
| 61 | VE3917 | NUT | ||
| 62 | VE4518 | BOLT, HEX HEAD | ||
| 63 | VE4519 | WASHER | ||
| 64 | VE4520 | NUT, HEX JAM | ||
| 65 | VE4699 | LOCKWASHER | ||
| 66 | VE4524 | JUMPER | ||
| 67 | VE4752 | CEMENT | ||
| 68 | VS8232 | TUBE, TORQUE | ||
| 69 | VE4742 | HUB, WHEEL |
